Limepoint Plus - Cement-Free Hydrated Lime Mortar

Verified by manufacturer 15 days ago

Instarmac Group plc

A cement-free hydrated lime gun-injected pointing mortar suitable for use with dense masonry and brick slip cladding tile systems where porosity is low.

Jump to:
+44 (0)1827 254400 Website

Application

Suitable for use with dense masonry and brick slip cladding tile systems where porosity is low.

Description

A cement-free hydrated lime gun-injected pointing mortar suitable for use with dense masonry and brick slip cladding tile systems where porosity is low.


Consistent in both colour and finish, Limepoint Plus mortar is pumped deep into the joint, providing a complete fill and allowing for a degree of flexibility when set.

The mortar is porous and allows for the passage of vapour and water through the mortar joint.


Limepoint Plus is suitable for pointing all brick slip cladding systems and is available in 14 colours to complement or contrast the brick finish.

Please refer to the individual system manufacturer for their specific installation procedure.


Features and benefits:

  • Fast application.
  • Joint widths: 5–25 mm.
  • Workability: 45 minutes.
  • Set time: 1 hour at 20°C.
  • Contains 20% recycled material.
  • Suitable for flexible construction.
  • Conforms to BS EN ISO 9001, ISO 14001 and ISO 45001.
  • 25 kg bags delivered on shrink-wrapped pallets.
  • Store in a cool, dry and frost-free area at temperatures between 5°C and 30°C.
  • Mortar is non-flammable.

General information

Color

Finish

Smooth

Material

Lime

Shape

Formless

Length

Bespoke

Width

Bespoke

Height

Bespoke

Uniclass

Pr_20_31_53_42 Injection mortarsPrimary

CAWS

F10/665 Pointing

Z21/310 Lime:sand mortar mixes

M20/57 Lime:sand

C41/820 Pointing

Z21/310 Lime:sand mortar mixes

M20/330 Proprietary lime:sand

M20/310 Lime:sand

C41/820 Pointing

Specification data - Injection mortars

Mix type

Dry packed blend of hydrated lime, selected silica sands and natural aggregates.

Guidance for specification option:

Limepoint Plus is a dry packed blend of lime complying with BS EN 459-1, GGBS complying with BS EN 15167 and BS EN 998-2, selected silica sands and natural aggregates complying with BS EN 13139 together with additives to provide water resistance, thixotropic properties, workability and colour.


Limepoint Plus is a traditional hydrated lime, sand, GGBS mortar.

Colour

Portland.

Charcoal.

Stone Grey.

Bathstone.

Brick Red.

Dark Red.

Light Brown.

Dark Brown.

Sandstone.

Natural.

Mid Brown.

Light Grey.

Mid Grey.

Dark Grey.

Standard

To BS EN 459-1, BS EN 15167, BS EN 998-2 and BS EN 13139.

Density

2.05 kg/m³.

Compressive strength - 28 days

9 N/mm².

Joint width

5–25 mm.

Water required for 25 kg mortar

3.75 L.

Workability

45 minutes at 20°C.

ThermalConductivity

P=50%, 0.86 W/m·K.
P=90%, 0.93 W/m·K.

Water absorption

0.28 kg/(m². min^0.5).

Water permeability

15/35 μ.

Yield per kg

13.5 L.

Guidance for specification option:

Approximately per 25 kg bag.

Shelf life

12 months.

Guidance for specification option:

From the date of manufacture printed on the bag unopened in the above conditions. High temperatures and high humidity will reduce shelf life.

Sustainability data

Contains Red List materials

No

Country of product manufacture

United Kingdom

Recycled content

As defined in clause 7.8 of BS EN ISO 14021

20 %
