Magnetic - mSwing Security Gate
Verified by manufacturer 5 months ago
Double swing door
Double swing door
Electric motor driven swing gate for barrier-free access.
Application
Suitable for indoor and outdoor applications, used to control individuals who want to enter or leave restricted areas, often where there are low safety requirements and are operated by a supervisor. Typical uses include:
- Visitor entrances.
- Wheelchair-friendly access.
- Transport routes.
- Escape route access.
Description
The mSwing glass swing doors are a versatile gate for entrances, wide passageways and escape routes. It is particularly suitable for areas where a flexible access solution is more practical than a high level of security, or the recording of people entering a building.
Depending on the number of users expected, there is the option of a single swing door, or a double swing door that provide passageway widths of up to 2400 mm. They have a two-way operation in entry and exit direction and an automatic closing after a set time span.
With mSwing, safe paths out of a building in emergency situations are ensured when combined with the optional emergency stop button.
Features and benefits:
- Versatile.
- Uni- or bi-directional direction of passage.
- mPost card-reader pillar allows for barrier-free access points.
- Compact accommodation of drive and control system in the centre column.
- Low impact forces for maximum personal safety.
- MHTM™ drive technology is designed for ten million opening and closing cycles.
- Single or double door configurations.
- Available in multiple passage width options.
- Escape route approval when used with the emergency stop button.
- CE marked.
General information
Color | Black Guidance for specification option: As standard. Silver Guidance for specification option: As standard. Other Guidance for specification option: Any standard RAL colour available. |
Finish | Other |
Material | Aluminium Glass |
Shape | Circle |
Width | 1000 mm 1200 mm 2400 mm |
Height | 994 mm 1800 mm |
Warranty description | One year Guidance for specification option: Standard 1 year warranty that can be extended subject to quotation. Contact manufacturer. |
Uniclass | |
CAWS | L20/490 Automatic doors L20/60 Doors |
Specification data - Half-height access control gates
Standard | Manufacturer's standard.Guidance for specification option:
|
Third-party certification | Escape route approval. |
Properties | |
Safety features | Emergency release and low energy drive.Guidance for specification option: Emergency release can be parameterised, fixed position or freely turning. |
Configuration | Double swing door. |
Housing | |
Type | Manufacturer's standard.Guidance for specification option: Height: 1092 mm. Maximum housing diameter, 183 mm. |
Material and finish | Aluminium. |
Colour | Silver.Guidance for specification option: As standard. Jet black.Guidance for specification option: As standard. (Similar to RAL 9005). White aluminium.Guidance for specification option: (Similar to RAL 9006). Customer specific.Guidance for specification option: Any standard RAL colour - more than 20 colour options are available, contact manufacturer and insert requirements. |
Panel | |
Type | Uni-directional.Bi-directional. |
Rotation | Swing. |
Speed of opening | 2.0–5.5 seconds.Guidance for specification option: Depending on barrier element dimensions. |
Material and finish | Glass wing, single-layer safety glass (ESG).Glass door, acrylic glass.Customer-specific barrier elements.Guidance for specification option: Consult manufacturer and insert requirements. |
Colour | Transparent. |
Size | |
Clear opening width (minimum) | 2400 mm. |
Overall width | Manufacturer guidanceOverall width is dependent on configuration and selected passage width. Consult manufacturer's literature. |
Height | 994 mm.Guidance for specification option: Standard. 1800 mm.Guidance for specification option: Full-height version. Custom.Guidance for specification option: Additional barrier hights are available on request. Contact manufacturer and insert requirements. Manufacturer guidanceBarrier height. |
Fixing | Screw mounting to finished floor surface.Mounting on unfinished floor.Guidance for specification option: By use of adjustable door foundation or frame. Raised access floor fixing. |
Security | Warning on forced entry.Not required. |
Credential Reader | |
Type | Required.Guidance for specification option: mPost card reader column. Consult manufacturer for options and insert details of card reader. Not required. |
Control unit | MGC.Guidance for specification option:
|
Power supply | 100–240 V a.c, 50–60 Hz.Guidance for specification option: Maximum power consumption, 45 W. |
Communications | Ethernet. |
Accessories | Passage direction indicator.Guidance for specification option: Passage direction indicator for mPost. Emergency button.Guidance for specification option: For triggering the alarm contacts and unlocking the barrier elements. Separation of access areas.Guidance for specification option: mGuide railing system for the separation of controlled and uncontrolled areas. Foundation frame.Guidance for specification option: For integration in new buildings, height adjustable between 10 and 15 cm. Not required. |
Lighting | Not required. Floor illumination. Red/green LED indicators. |
Weight | 40 kg (approximate). Guidance for specification option: Excludes blocking element. |
Duty cycle | 100%. |
TemperatureRange | −30 to +55 °C. Manufacturer guidanceOperating and storage temperature range. |
Ingress protection (IP) rating | IP54. |
RelativeHumidity | 95% (maximum), non-condensing. |
SoundPressure | ≤70 dB (A). Manufacturer guidanceAirborne sound pressure level (LpA). |
Angle | Adjustable from 0° – ±300°. Manufacturer guidanceOpening angle. |
Sustainability data
Country of product manufacture | Germany |
BIM objects
| Platform | Compatible | Version |
|---|---|---|
 IFC | - | 1 |
 Revit | - | 1 |
