Mapeshield I

Verified by manufacturer 8 months ago

Mapei (UK) Ltd

Pure zinc coated anodes for galvanic cathodic protection against corrosion of reinforcement rods.

Jump to:
+44 (0)121 508 6970 Website

Application

  • Basins.
  • Beams and columns.
  • Car parks.
  • Floor slabs.
  • Foundations.
  • Front edges of balconies.
  • Piles and abutments on bridges and viaducts.
  • Pre-fabricated reinforced concrete structures.

Description

Pure zinc anodes coated with a special conductive paste, for galvanic cathodic protection against corrosion of reinforcement rods in new structures and in structures requiring repair. It is made up of a multi-layered zinc core with a large surface area, covered with a special conductive paste which keeps the system active over the years.

It is particularly recommended for protecting reinforcement rods against corrosion in structures of art requiring repair work and also a number of advantages if applied on new reinforced structures for protection against corrosion, especially if they come in to contact with aggressive agents.

General information

Color

Blue

Material

Zinc

Uniclass

Pr_35_31_68_99 Zinc platingPrimary

CAWS

C42/315 Protective coating to reinforcement

Specification data - Zinc plating

Product Reference

Mapeshield I 10/10

Guidance for specification option:

100 x 50 mm, 12 mm high.

Mapeshield I 10/20

Guidance for specification option:

100 x 50 mm, 15 mm high.

Mapeshield I 30/10

Guidance for specification option:

300 x 50 mm, 10 mm high.

Mapeshield I 30/20

Guidance for specification option:

300 x 50 mm, 12 mm high.

Colour

Light blue.

Weight

Mapeshield I 10/10: 230 g (total), 168 g (zinc).

Mapeshield I 10/20: 320 g (total), 245 g (zinc).

Mapeshield I 30/10: 450 g (total), 340 g (zinc).

Mapeshield I 30/20: 570 g (total), 450 g (zinc).

Yield strength

>130 N/mm² (longitudinal), >150 N/mm² (transversal).
