Application

Suitable for the passive fire protection of steel, concrete, concrete sheet composite slab structural elements, fire compartmentation and firestop strips.

Description

Gypsum-based fireproof mortar with thermal insulation properties for passive fire protection.

Features and benefits:

  • Formulation with light high performance fillers.
  • Non-combustible.
  • Can be sprayed by discontinuous machine to improve its performance by 15%.
  • Asbestos-free – complies with regulations 2003/18/EC and RD 396/2006.
  • Good adhesion on different substrates.
  • Light and low abrasion with the use of spraying equipment, saving on consumables.
  • Low protection thicknesses, saving on transport and labour.
  • Wide range of fire solutions.

General information

Color

White

Finish

Roughcast

Smooth

Material

Gypsum

Shape

Formless

Uniclass

Pr_20_31_53_31 Fire-resisting mortarsPrimary

CAWS

P12/342 Fire-resisting mortars

Specification data - Fire-resisting mortars

Classification data

Material

Gypsum-based.

Fire resistance

Guidance for specification option:

Performance varies depended on application:

  • Protection of metal structures (EN 13381-4): open beams and columns and tubular profiles up to R240.
  • Protection of concrete structures (EN 13381-3): beams, columns, solid slabs, walls and floor slabs up to REI 240.
  • Protection of concrete steel composite slabs (EN 13381-5): protection of composite slabs up to REI 180.
  • Non-load bearing walls (EN 1364-1): vertical compartmentation wall with EI 120 rating.
  • Firestop strips (in accordance with Ministry of Industry protocol): anchored to purlin system, EI 180.

Consult manufacturer for more details and insert requirements.

Colour

Antique white.

Apparent density

350 +/-15% kg/m³.

Cured density

Discontinuous machine: ≥ 480 +/-15% kg/m³.
Continuous machine: 550 +/-15% kg/m³.

Guidance for specification option:

Discontinuous machine:

Average value obtained under laboratory conditions, with a mixing speed of 60 rpm for 90 seconds. If any of these parameters are modified, both the final density and the performance could vary. Lower density at higher speed, and higher density with a shorter mixing time.

Continuous machine:

Average value obtained under laboratory conditions.

Manufacturer guidance

Hardened density.

Performance

Discontinuous machine: 3.5 +/-15% kg/m²/cm.
Continuous machine: 4.1 +/-15% kg/m²/cm.

Guidance for specification option:

Discontinuous machine:

Average value obtained under laboratory conditions, with a mixing speed of 60 rpm for 90 seconds. If any of these parameters are modified, both the final density and the performance could vary. Lower density at higher speed, and higher density with a shorter mixing time.

Continuous machine:

Average value obtained under laboratory conditions.

Adhesion

≥ 0.1 MPa.

Guidance for specification option:

In accordance with EGOLF SM/5.

CompressiveStrength

To EN 1015-11, ≥ 0.2 MPa.

Flexural strength

To EN 1015-11, ≥ 0.2 MPa.

Reaction to fire

To EN 13501-1, Class A1.

ThermalConductivity

To UNE EN 12667, 0.087 W/m.K.

Noise reduction coefficient

To ASTM C423, 0.2.

Guidance for specification option:

At 20 mm thickness.

Weighted sound absorption coefficient

To UNE EN ISO 354, αw=0.2.

Guidance for specification option:

At 20 mm thickness.

VOC emissions

To EN 16516, < 0.035 mg/m³.

Third-party certification

CE marked.
Indoor Air Comfort, Gold.
Cradle to Cradle certified.
Emissions Dans L'Air Interieur: A+ rating.

Sustainability data

Material

Gypsum

Literature

Perlifoc HP ECO + - Data Sheet

Perlifoc HP ECO + - Data Sheet
