ProSys Urinal Frame

Verified by manufacturer 7 months ago

Ideal Standard (UK) Ltd

Urinal frame for use with Sensorflow specific urinals within the Armitage Shanks portfolio

Jump to:
+44 (0)870 122 8822 Website

Application

For use as urinal frame.

Description

Frame with easy fix system offering a secure in wall solution for mounting specific urinals within the Armitage Shanks portfolio


Features and benefits:

  • Commercial use.
  • Easy installation.
  • Secure mounting of urinal.
  • Adjustable wall brackets.
  • Corrosion resistant.
  • Frame tested to 130 kg.
  • Weight: 12.00 kg.
  • For use with specific urinals only when used with the Sensorflow electronic flushing system, please see Options for details.

General information

Color

Silver

Finish

Other

Material

Steel

Shape

Other

Length

120 mm

Width

500 mm

Height

1150 mm

Warranty description

Ten year

Uniclass

Pr_40_20_93_87 WC cistern fittingsPrimary

CAWS

N13/302 WCs and flushing valves

N13/300 WCs and cisterns

N13/66 Pre-plumbed frame system

Specification data - WC cistern fittings

Integral accessories

Fixing bolts supplied.

Dimensions

500 x 170 x 1000 mm.

Guidance for specification option:

W x D x H.

Sustainability data

Contains Red List materials

No

Country of product manufacture

Portugal

BIM objects

Platform Compatible Version
Revit
-

1

Literature

Prosys

Prosys
