Raincheck - Acoustic Damping Membrane
Verified by manufacturer 2 months ago
Alcumus SafeContractor
Certificate type
Easy to install acoustic damping membrane for reducing rain noise through metal profile roofing.
Application
Acoustic damping membrane for metal profile roofing. Suitable for:
- Commercial, industrial and educational environments.
- Suitable for both new build and retro fit installations.
Description
SRS Raincheck is an acoustic damping membrane for metal profile ceilings and a solution to the issue of rain noise in commercial, industrial and educational environments, ranging from commercial offices and industrial factory units.
Features and benefits:
- BB93 solution to rain noise in schools.
- Improves learning and working conditions.
- Reduces rain noise through all metal profile roofs.
- Manufactured in association with DEDPAN Technology.
- Lightweight and flexible material.
- Supplied in self adhesive rolls and strips.
- Extremely high performance.
- 1 mm thick.
- Tested to BS EN ISO 140-18:2006.
General information
Color | Green |
Finish | Other |
Material | Plastic |
Shape | Other |
Length | 15000 mm |
Width | 245 mm |
Height | 1 mm |
Uniclass | |
CAWS | H31/10 Metal H31/120 Metal |
Specification data - Plastics sheets
Material | Plastics.Guidance for specification option: Consult manufacturer for details. |
Purpose | Acoustic control layer. |
Standard | To BS EN ISO 140-18 and BS EN ISO 15186-1. |
Performance characteristics | |
Fire performance | Flammability: Pass FMVSS 302. |
Physical properties | |
Colour | Green. |
Weight (minimum) | 1.90 kg/m². |
Dimensions | |
Thickness (minimum) | 1 mm. |
Adhesive | Acrylic P.S. |
Maximum temperature | 190℃ (short exposure). Manufacturer guidanceMaximum temperature tolerance. |
Flexibility | Flexible to 5℃. Guidance for specification option: (Bent around a 30 mm mandrel). |
Sustainability data
Country of material origin | United Kingdom |
Country of product manufacture | United Kingdom |
Material | Plastic |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 0 % |
