Recessed Track System

Verified by manufacturer 6 months ago

Tillys Interiors

Recessed curtain track system, which fits within a single thickness of plasterboard.

Jump to:
+44 (0)23 9225 2525 Website

Application

Suitable for light- to medium-weight curtains. Recess fix through track profile.

Description

Recessed curtain track system. Suitable for light- to medium-weight curtains.


Features and benefits:

  • Track profile recesses into ceiling.
  • Fits within a single thickness of plasterboard.
  • Hand operation.
  • Option of roller gliders.
  • 60/ 80 mm Ripple spacing.
  • Suitable for bay windows.
  • Angle bend - 20 cm radius.
  • Curved bend - any large radius.

General information

Color

White

Other

Guidance for specification option:

This track and channel can be painted to any RAL colour, (though the standard is white).

Finish

Powder-coated

Material

Aluminium

Length

Bespoke

Width

14 mm

Height

11 mm

Uniclass

Pr_40_30_20_96 Window curtain supportsPrimary

CAWS

N10/60 Curtain supports

N10/230 Curtain supports

Specification data - Window curtain supports

Support

Curtain tracks.

Overall length

Guidance for specification option:

Insert requirement. The track is made-to-measure. The maximum continuous length is 6 metres but the tracks can also be joined.

Colour

White.

Operation

Hand-drawn.

Ripple hand-drawn.

Integral accessories

Roller gliders.

Bends

Not required.

20 cm radius.

Fixing:

Recess fix through track profile.

Literature

RTS12 Specification Guide

RTS12 Specification Guide
