Application

Suitable for substrates that are prone to movement or which contain residual moisture.

Description

A heat weldable and glass-reinforced, composite rubber membrane with an EPDM core. The underside is partially coated with self-adhesive polymer modified bitumen, with a release film.


Features and benefits:

  • Fully elastic down to temperatures of -30°C.
  • Resistant to the effects of ozone, UV and infrared radiation without additional surface protection.
  • Resistant to a wide range of environmental chemicals and atmospheric emissions.
  • Compatible with bitumen.
  • Contains no chlorine and plasticizers.
  • Highly slip resistant even when wet.
  • No shrinkage throughout the entire service life.
  • Life expectancy of decades.
  • Recyclable.
  • CE- Marking to BS EN 13956.
  • Due to the partially coated self-adhesive underside, RESITRIX® SK Partial Bond allows permanent vapour pressure dissipation.
  • Particularly advantageous for substrates that are prone to movement or which contain residual moisture.

General information

Color

Black

Finish

Anti-slip

Material

EPDM

Rubber

Bitumen

Shape

Rectangle

Length

10000 mm

Width

1000 mm

Height

2.5 mm

Warranty description

20 year

Uniclass

Pr_25_57_51_66 Polymeric membranesPrimary

CAWS

J41/115 Single-layer reinforced bitumen membrane warm deck roof covering

J41/125 Single-layer reinforced bitumen membrane inverted roof covering

J41/135 Single-layer reinforced bitumen membrane cold deck roof covering

J41/405 Single-layer reinforced bitumen waterproof covering

J42/110 Warm deck roof covering

J42/120 Inverted roof covering

J42/130 Cold deck roof covering

J42/400 Waterproof membrane

Product range

Roofing Membranes

Specification data - Polymeric membranes

Material

Ethylene propylene diene monomer (EPDM); Rubber; Glass.

Standard

To DIN EN 13956, DIN EN 13967, DIN 18531, DIN 18195, DIN 18532, DIN 18533, DIN 18534 and DIN 18535.

Third-party certification

British Board of Agrément (BBA) Certificate; CE Marked.

Width (minimum)

1000 mm.

Thickness (minimum)

2.5 mm (± 10%).

Colour

Black.

Accessories

Not required.

FG35 Primer.

Fixing

Fully primed surface using FG 35 primer.

Partially bonded.

Guidance for specification option:

Partially bonded without FG 35 primer, where the substrate consists of a fresh coating of bitumen.


Partly primed surface using FG 35 primer.

Weight

2.75 kg/m².

Tensile strength (to EN 12311-2)

Longitudinal: 361 N/50 mm; Transverse: 333 N/50 mm.

Elongation at break (to EN 12311-2)

Longitudinal and transverse: 600%.

Dimensional stability (to EN 1107-2)

Longitudinal: +0.1%; Transverse: +0.2%.

Flammability (to DIN 4102)

B2.

Manufacturer guidance

Fire behaviour to DIN 4102-7 and DIN EN 1187:

  • Resistant to flying sparks and radiating heat.

Reaction to fire (to EN 13501-1)

Class E.

Sustainability data

Country of material origin

Germany

Country of product manufacture

Germany

Recyclability

Recyclable
