Rockfon® Canva™ Hanging Divider - Acoustic hanging divider

Verified by manufacturer 4 months ago

Canva™ Hanging Divider - 1800 x 600 mm

Rockfon Variant:

Stone wool absorber, powder coated aluminium frame and a printed polyester based textile surface hanging acoustic zoning solution.

Jump to:
+44 (0)208 2227457 Website

Application

Suitable for use in areas where zoned sound absorption is required in open plenum environments, including the following:

  • Education;
  • Healthcare;
  • Leisure;
  • Office;
  • Retail.

Description

A ceiling suspended sustainable zoning solution in open plenum environments where acoustic and aesthetics needs to be flawless. It is manufactured from a stone wool absorber, powder coated aluminium frame and a printed polyester based textile surface.


Features and benefits:

  • Aesthetically pleasing.
  • Detachable, washable and replaceable canvas.
  • Choice of 34 inspirational Colors of Wellbeing or option to design a personalised graphic layout for that personal touch.
  • Customizable to suit the mood, function or brand preference of any user.
  • Free hanging acoustic panel suspended with wires from the ceiling.
  • Panel arrives fully assembled.
  • Easy and fast to install.
  • Possibility to customize panel size on demand (minimum size (W x H) 600 x 600 mm and maximum size (W x H) 2400 x 2000 mm).
  • 61 mm frame depth.
  • Stone wool provides no sustenance to microorganisms and is fully recyclable.
  • White or black powder coated matt aluminium frame option.
  • Design cooperation with Danish acoustic design company Akuart.
  • Awarded the Finnish M1 emission classification for building materials and the Danish Indoor Climate Label for low emission products.


Cleaning:

  • Frame: Vacuum, damp cloth and low pressure foam cleaning.
  • Canvas: Vacuum, damp cloth and washing in normal machine wash cycle up to 70 degrees.

General information

Color

White

Black

Green

Blue

Yellow

Show more

Finish

Matt

Powder-coated

Material

Fabric

Stonewool

Aluminium

Polyester

Shape

Rectangle

Length

1800 mm

Bespoke

Width

600 mm

900 mm

1200 mm

Bespoke

Height

61 mm

Uniclass

Ss_30_25_22_01 Acoustic baffle suspended ceiling systemsPrimary
Pr_35_93_13_80 Sound attenuator infill units

CAWS

M52/110 Wallcoverings

K13/170 Acoustic panel lining

K13/170 Acoustic panel lining

Specification data - Acoustic baffle suspended ceiling systems

Ceiling support

Suspended with wires from the ceiling.

Ceiling units

Free hanging rigid acoustic panel.

FrameMaterial

Aluminium.

Guidance for specification option:

61 mm powder coated matt aluminium frame.

Frame colour/ finish

White, powder coated matt.

Black, powder coated matt.

Weight

9 kg.

Manufacturer guidance

Weight per unit.

Application

Ceiling mounting.

Purpose

Absorber.

Sound absorption

Class A.

Reaction to fire

To EN 13501-1, Class B-s1, d0.

Size (length x width)

1800 x 600 mm.

Thickness (overall)

61 mm.

Profile

Geometric profile.

Edges

Square.

Surface pattern

Texture weave.

Guidance for specification option:

As standard. Printed polyester based textile.

Graphic print.

Guidance for specification option:

Optional. Printed polyester based textile, custom graphic print available on request. Consult manufacturer and insert requirements.

Colour

Seaweed.

Eucalyptus.

Sage.

Mint.

Space.

Show more

Manufacturer guidance

Canvas colours.

Sustainability data

Contains Red List materials

No

Country of product manufacture

Denmark

Recyclability

Fully recyclable stone wool.
