Stainless Steel Tall Cabinets

Verified by manufacturer 6 months ago

Anderson, GEC Ltd

Stainless steel tall cabinets are available with hinged or sliding doors and are available in standard or custom sizes.

Jump to:
BOS
+44 (0)1442 826999 Website

Application

Designed for a wide range of applications and environments, including commercial and domestic kitchens, tea points, offices, libraries, schools, hospitals, hostels, retail environments and bars.


Suitable for:

Commercial projects

Kitchens

Residential

Description

A versatile range of sleek, robust and hygienic storage facilities.


The standard range includes wall-mounted, high level cabinets, and wall-mounted or free-standing, low level cabinets and drawer units.


All cabinets are designed to complement GEC Anderson sinktops, worktops and other stainless steel fittings. If stainless steel cabinets are not required or are inappropriate, GEC Anderson stainless steel doors and drawer-fronts are available for fitting to non-stainless steel cabinets.


In addition to standard sizes, the cabinets and drawer units can be supplied made-to-measure.


Material:

  • 1 mm brushed satin stainless steel: Grade: EN 1.4301.


Cabinet mounting:

  • Wall (high level) cabinets are wall-hung on surface fixed bracket, which allows easy removal for cleaning.


Shelves:

  • One vertically adjustable shelf per cabinet.


Doors and drawer fronts:

  • Double skin construction with waterproof core. A fire resistant core is also available.
  • Pre-hung (left or right-handed).
  • Key operated lock optional.
  • Universal hinges with three-plane adjustment and quick release lever for instant door removal.


Drawer units:

  • Smooth and accurate roller-bearing runners.
  • Individual drawers available (e.g. for mounting below worktops).


Cabinet mounting:

  • 30 x 30 mm stainless steel legs with manually adjustable plastic feet.
  • 40 x 40 mm stainless steel hydraulically adjustable (0–200 mm) legs with single fold-away handle.
  • Chrome-plated brass feet – optional.
  • Floor fixing flanges/ plates – optional.
  • Free-standing on adjustable feet, with or without kickplate: 160 mm high.
  • Free-standing on lockable zinc-coated steel castors (with 125 mm diameter rubber tyre): 160 mm overall height.
  • Wall mounted stainless steel cantilever brackets.


Drawers:

  • Two, three or four drawer.
  • Individual drawers available (e.g. for mounting below worktops).


Doors and drawer fronts:

  • Doors and drawer fronts are available in any size, for use with cabinets by others.
  • Plain stainless steel, or glass frosted, clear or wired in stainless steel frame.


Handles:

  • Handles: Choice of continuous recessed, reversible handle, vertical or horizontal, or stainless ‘D’ handle, or back-slope edge.
  • Can be supplied without handle for fitting of hardware by others.


Dimensions – Cabinet depth (excluding doors):

  • Wall cabinets: 355 mm.
  • Base (low level) cabinets and drawer units: 580 mm.
  • Non-standard sizes made to order.


Height:

  • Base (low level) cabinets and drawer units: 515 mm/ 700 mm.


Worktops:

  • GEC Anderson stainless steel worktops.


Bowls:

  • GEC Anderson stainless steel integrally welded worktops.

General information

Color

Silver

Finish

Satin

Brushed

Material

Stainless steel

Steel

Shape

Rectangle

Length

Bespoke

Width

Bespoke

Height

Bespoke

Warranty description

Five year

Uniclass

Pr_40_30_87_42 Kitchen drawer unitsPrimary

CAWS

N10/135 Storage and display units

N11/320 Fitted wall units

N11/310 Fitted base units

N11/10 Fitted base units and wall units

Product range

Made to Measure / Cabinets

Specification data - Kitchen drawer units

Form

Perimeter tall units.

Dimensions

As drawing.

Manufacturer guidance

  • Bespoke, insert requirements.
  • Wall cabinets: 355 mm depth excluding doors.
  • Base (low level) cabinets and drawer unit depth: 580 mm.
  • Base (low level) cabinets and drawer unit height: 515 mm/ 700 mm.
  • Non-standard sizes made to order.

Surface finishes

Brushed satin.

Doors

-

Material

Stainless steel to EN 1.4301.

Frosted glass in stainless steel frame.

Wire frosted glass in stainless steel frame.

Finish and colour

Brushed satin.

Base unit

As drawing.

515 mm.

700 mm.

Wall cabinets

As drawing.

700 mm.

Single cabinets

400 mm.

500 mm.

600 mm.

Double cabinets

800 mm.

1000 mm.

1200 mm.

Drawer units

400 mm.

500 mm.

600 mm.

800 mm.

1000 mm.

Number of drawers

2.

3.

4.

Mounting

As drawing.

Castors.

Chrome-plated brass feet.

Floor fixing flanges/ plates.

Stainless steel hydraulically adjustable legs.

Show more

Sustainability data

Contains Red List materials

No

Country of material origin

Europe

Country of product manufacture

Europe

Recyclability

100

Recycled content

As defined in clause 7.8 of BS EN ISO 14021

0 %

BIM objects

BOS

NBS BIM Object Standard

This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.

Find out more about the NBS BIM Object Standard.

Platform Compatible Version
IFC
-

1

Revit

Revit 2017

1

Literature

GEC Anderson Combined Product Literature- The Complete Range Overview with Detailed Specification Data, Examples, Applications, History & Insight into GEC Anderson Stainless Steel
