SX-3068 Orchid Transparent Dichroic Film - Window Film

Name: SX-3068 Orchid Transparent Dichroic Film - Window Film
Brand: Glass Films Europe
SKU: sM2mPd4cztnUFxEVJFQroC

Verified by manufacturer 3 months ago

Glass Films Europe

Third party certifications:

BS EN 13501-1
Certificate type

Dichroic polyester film for use on interior glass surfaces.

Jump to:

+44 (0)800 970 6366 Website

Application

For application to interior glass surfaces.

Description

Dichroic polyester film made of multi-layered durable polyester for colour shifting special effects. The colours shift as the viewing angle changes. The colours when viewed with light behind are violet, blue, red orange and yellow. When viewed with less light behind the film the colour is reflective silver and gold.

SOLYX & SIMGLAS Decorative Films must be installed by a Glass Films-approved window film installation company in order to retain the five-year manufacturer warranty. Please contact manufacturer to locate your nearest approved window film installer.

General information

Color	Clear
Finish	Film
Material	Polyester
Shape	Other
Width	1371.6 mm
Warranty description	Five year Guidance for specification option: Subject to manufacturer’s installation requirements, must be installed by a Glass Films-approved window film installation company. Consult manufacturer for details.

Uniclass	Pr_25_57_51_60 Plastics window filmsPrimary
CAWS	L40/630 Manifestation L40/96 Manifestation L40/95 Window film L40/610 Window film

Product range	Coloured Glass Films

Specification data - Plastics window films

Purpose	Decorative.
Material	Multi-layered dichroic polyester.
Colour	Transparent. Guidance for specification option: The colours when viewed with light behind (daytime looking from inside to outside) are violet, blue, red orange and yellow. When viewed with less light behind the film (daytime from outside) the colour is reflective silver/ gold.
Dimensions	- Manufacturer guidance Roll width, 1371.6 mm.
Fire performance	Class B, s1, d0 in accordance with BS EN 13501-1. Guidance for specification option: When applied to glass or plastic surfaces: Horizontal Burn (Flame Spread) ASTM D-635 inch Less than 1.0 UL 94 Rating UL Classification V-O Class A 0-25 Flame Spread Index 0-450.

Adhesive	Clear, pressure-sensitive.
Film thickness	38 micron.
Release Liner	Plottable synthetic.
Light transmission	65%.
Light reflectance	15%.
UV Transmission	20%.
Solar Energy Rejected	45%.
Glare reduction	35%.

Sustainability data

Country of material origin	United States
Country of product manufacture	United States
Material	Polyester
Manufacturing plant location	Cornell Pl, Maryland 21703, USA
Expected Life	Ten year Guidance for specification option: Up to ten years.
