SXGF-0500 Clear Frosted Safety Window Film

Verified by manufacturer 5 months ago

Glass Films Europe Third party certifications:
  • BS EN 13501-1

    BS EN 13501-1

    Certificate type

Clear frosted safety film.

Jump to:
+44 (0)800 970 6366 Website

Application

Interior and exterior applications.

Description

High strength impact modified clear frosted safety film.


Features and benefits:

  • For interior and exterior use.
  • Flammability rating of class B-s1, d0 to BS EN 13501-1:2018.
  • Made from 127 µm-thick vinyl.
  • Supplied in fixed roll width of 54” (132 cm) and 60” (152 cm).
  • Supplied with a paper liner and water-based acrylic, clear, pressure-sensitive adhesive.
  • Infra-red transmission of 74%.


ASTM E84 – Standard Test Method for Surface Burning Characteristics of Building Materials. Achieved level: Class 1 (a).

General information

Color

Clear

Finish

Micro-textured

Material

Vinyl

Width

1371.6 mm

Warranty description

Five year

Uniclass

Pr_25_57_51_60 Plastics window filmsPrimary

CAWS

L40/95 Window film

L40/610 Window film

Product range

Frosted Glass Films

Specification data - Plastics window films

Purpose

Privacy.

Material

Vinyl.

Colour

Clear.

Dimensions

1371.6 mm.

Guidance for specification option:

Fixed roll width.

Fire performance

To BS EN 13501-1:2018, Class B, s1, d0.

Adhesive

Permanent acrylic, clear, pressure-sensitive.

Film thickness

127 µm.

Guidance for specification option:

127 micron rigid polymeric calendared vinyl.

VisibleLightTransmittance

56%.

SolarAbsorption

18%.

TensileStrength

60 lb./in.

Abrasion resistance

5%.

Elongation at break

150%.

Service temperature range

-40°F to +200°F.

Release Liner

38 micron clear Polyester.

Sustainability data

Country of material origin

United States

Country of product manufacture

United States

Material

Vinyl

Manufacturing plant location

Expected Life

Ten year

Guidance for specification option:

Up to ten years.

Third party certifications

BS EN 13501-1

BS EN 13501-1

Solyx Vinyl Fire Certificate
