Teaching Wall - 2 Door Sliding Top Unit

Verified by manufacturer over a year ago

Nu-Style Products Ltd

Top unit with sliding doors, suitable for use in teaching walls.

Jump to:
BOS
+44 (0)1224 823000 Website

Application

Schools, nursery, offices, hospitals, airports.

Description

Top unit with sliding doors, suitable for use in teaching walls.


Features and benefits:

  • Compatible with other products in the Nu-Style educational furniture range.
  • Supplied fully assembled with doors on a slide track, and four fixed or adjustable shelves.
  • Available in a wide range of colours.


General information

Color

-

Manufacturer guidance

Available in a wide range of colours, consult manufacturer and insert requirements.

Finish

Melamine

Laminate

Material

Medium-density fibreboard (MDF)

Size

1500 x 2020 x 582 mm

Guidance for specification option:

Height x width x depth.

1500 x 1000 x 582 mm

Guidance for specification option:

Height x width x depth.

Uniclass

Pr_40_30_87_12 Classroom storage unitsPrimary

CAWS

K30/250 Storage walls

N10/135 Storage and display units

Specification data - Classroom storage units

Storage units

Two-door sliding unit.

Dimensions

1500 x 2020 x 582 mm.

Guidance for specification option:

Height x width x depth.

1500 x 1000 x 582 mm.

Guidance for specification option:

Height x width x depth.

Material

Medium-density fibreboard (MDF).

Guidance for specification option:

18 mm-thick moisture resistant.

Finish

Melamine-faced chipboard (MFC).

Guidance for specification option:

  • 18 mm-thick melamine-faced chipboard (MFC).
  • Available in a selection of colours from the Swiss Krono One World Collection; consult literature for details.

High-pressure laminate (HPL).

Guidance for specification option:

  • Moisture resistant medium density fibreboard (MDF) with 20 mm-thick high-pressure laminate (HPL) on both sides.
  • Available in a selection of colours from the Formica Fundamentals range, as well as colours by Formica and Polyrey; consult literature for details.

Colour

-

Manufacturer guidance

Available in a wide range of colours, consult manufacturer and insert requirements.

Exposed edges

Plastics strip.

Guidance for specification option:

MFC board

  • Swiss Krono; square edged/ lipped with 2 mm-thick polyvinyl chloride (PVC).


HPL board

  • Square edged/ lipped with 2 mm-thick acrylonitrile butadiene styrene (ABS).


Product Reference

Teaching Wall - 2 Door Sliding Top Unit

Shelving

None.

Adjustable.

Fixed.

BIM objects

BOS

NBS BIM Object Standard

This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.

Find out more about the NBS BIM Object Standard.

Platform Compatible Version
Revit

Revit 2017

1

IFC
-

1
