Technowood Natural Veneer Coated GRP (Glassfibre Reinforced Plastic) Panels
Verified by manufacturer 3 days ago
QA Certificate
Certificate type
Glass-reinforced plastic (GRP) panels with a natural wood veneer.
Application
Suitable for exterior and interior use in place of timber.
Since the panels are very thin - 4.5 mm only, ideal for areas where minimum build out required.
Description
Glass-reinforced plastic (GRP) panels with a natural wood veneer.
Features and benefits:
- Provides the visual and tactile effects of natural wood.
- Requires 98% less timber than equivalent sold wood projects.
- Minimal maintenance required.
- Standard length on panels is 3.2 metres and can be produced shorter or up to 6 metres upon special request.
- As a standard, the end points of the profiles are open; and they can optionally be produced as closed with solid wood. Straight or carved options available.
- Five colours available as standard; specific colour production can be made for orders above 1000 linear metres.
- Veneered aluminium panels also available, specified separately.
General information
Color | Brown Beige Black Copper Cream Manufacturer guidanceEight colours available. |
Finish | Veneered |
Material | Glass Reinforced Plastic (GRP) |
Shape | Rectangle Other |
Length | 3200 mm 6000 mm |
Width | 100 mm 150 mm 200 mm |
Height | 4.5 mm |
Warranty description | 20 year |
Uniclass | |
CAWS | H41/130 GRP features H41/110 GRP single-skin cladding |
Specification data - Glass fibre-reinforced plastics (GRP) profiled sheets
Thickness (nominal) | As profile. |
Profile | 160 mm EGP-1635.Guidance for specification option: Overlapping profile. Wall thickness: 3.5 mm. Weight (per unit): 1.460 kg. 100 mm EGP-U1000.Guidance for specification option: Curved profile. Wall thickness: 3 mm. Weight (per unit): 0.560 kg. 200 mm EGP-A2100.Guidance for specification option: Flat profile. Wall thickness: 10 mm. Weight (per unit): 3.680 kg. 200 mm EGP-A2080.Guidance for specification option: Flat profile. Wall thickness: 8 mm. Weight (per unit): 2.800 kg. 200 mm EGP-A2060.Guidance for specification option: Flat profile. Wall thickness: 6 mm. Weight (per unit): 2.131 kg. 200 mm EGP-A2040.Guidance for specification option: Flat profile. Wall thickness: 4 mm. Weight (per unit): 1.562 kg. 50 x 50 mm EGP-L5050.Guidance for specification option: L-profile. Wall thickness: 10 mm. Weight (per unit): 1.840 kg. 50 x 95 mm EGP-L5095.Guidance for specification option: L-profile. Wall thickness: 10 mm. Weight (per unit): 2.668 kg. 50 x 200 mm EGP-L5020.Guidance for specification option: L-profile. Wall thickness: 10 mm. Weight (per unit): 4.600 kg. |
Length | 3200 mm.6000 mm. |
Finish as delivered | Natural wood veneer. |
Colour | Teak.Guidance for specification option: Suitable for external environments; water-resistant. High resistance to insects and fungal damage. Mahogany.Guidance for specification option: Hardwood, suitable for varnishing. Multi-purpose. Oak.Guidance for specification option: Resistant to weather conditions and humidity. Walnut.Ash.Bamboo.Manufacturer guidanceFSC-certified veneer. Specific colour production can be made for orders above 1000 linear metres; consult manufacturer for details. |
Sustainability data
Contains Red List materials | No |
Country of material origin | Turkey |
Country of product manufacture | Turkey |
Recyclability | 100% |
Third party certifications
QA Certificate
CERTIFICATES (ISO CE FSC EPD) 2021 EN
Literature
Test report 10-001070-PB03-K99-03-en-01
TECHNOWOOD VARNISH VENEER CHART
Interim test report No. 10-001070-PB01-K99-en-01
Artificial Weathering Test report
