DS13 Timber Sliding Door (Traditional)
DS13 Timber Sliding Door (Traditional)
Timber sliding doors.
Application
Suitable for limited space areas including kitchens, entrances, and bedrooms with Juliet balconies.
Description
Timber sliding doors with a gliding rail system, designed to provide uninterrupted views and more natural light.
Features and benefits:
- Available in a wide range of configurations to suit the layout of the room and the size of the reveal.
- Weather rating: Tested to exposure category 2000.
- Thermal performance: A rated as standard. Triple glazed options available.
- The specialist handle enables the door to be locked with a 10 mm gap to provide secure ventilation.
- Environmentally friendly designs, materials and processes.
- Good acoustic performance.
- Secured By Design and PAS 24 compliant.
- Security laminated glazing is available for improved acoustic performance and safety.
- Dual seal design provides excellent draught proofing.
- Can withstand heavy pane weights.
General information
Color | Other Guidance for specification option: Options from the RAL Classic, Design and Effect ranges as well as British Standard and NCS colours, and complementary colour matching to all leading manufacturers’ ranges. |
Finish | Painted Stained |
Material | Timber Glass Wood |
Shape | Rectangle |
Length | Bespoke |
Width | Bespoke |
Height | Bespoke |
Warranty description | Ten year Guidance for specification option: Ten year: Glazing unit, weather seals, hardware, and paint finish. Please note: Ten year warranty is only available on painted finish in the traditional and contemporary ranges. Other Guidance for specification option: Consult manufacturer for details. |
Uniclass | |
CAWS | L20/270 Wood doors L20/30 Wood doors L20/60 Doors L20/520 Sliding doors |
SKU Code | DS13 |
Specification data - Sliding door and partition sets
Classification data | |
Performance | External. Guidance for specification option:
Insert required values for air permeability, water tightness, and resistance to wind load. |
Arrangement | Two rows. Three rows. Manufacturer guidanceConsult manufacturer's literature for further details. |
Track system | Glide rail system. Guidance for specification option: Insert requirements for track colour/ finish. |
Door leaves | |
Construction | Engineered redwood. Engineered grandis. European oak. Accoya. Manufacturer guidanceAppearance class: J10 for glazing beads, drips and similar. J40 or better for all other members. |
Finish and colour | George Barnsdale paint system. Guidance for specification option: Four coats on opaque/ three coats on translucent. Options from the RAL Classic, Design and Effect ranges as well as British Standard and NCS colours, and complementary colour matching to all leading manufacturers’ ranges. Dual colour options also available. Consult manufacturer and insert requirements. |
Operation | Manual. Guidance for specification option: Soft close and soft open and close options available. Powered. |
Hardware | Manufacturer's standard. Guidance for specification option: A range of furniture finishes are available. Consult manufacturer for details. |
Accessories | Not required. Cill extension. Cill closer. Draught strip. Manufacturer guidanceConsult manufacturer for further details and insert requirements. |
Configuration | Sliding door - traditional plus. Manufacturer guidanceInsert size requirement. |
Type | Factory glazed, traditional drained and ventilated. Guidance for specification option: Glazing unit: To meet performance specification. Triple glazed options available, consult manufacturer for details. See glazing style options guide for further details. Manufacturer guidanceDoor Leaf Glazing Type. |
Standard | To BS 644. To BS EN 942. |
Security level | Not required. To Secured by Design standard/ PAS 24. Guidance for specification option: When required by Building Regulations Document Q. |
Acoustic performance rating | Manufacturer's standard. Manufacturer guidanceCertain options may affect the availability of other options and the performance levels. Consult manufacturer for details. |
Thermal performance | 0.9–1.3 W/m2K. Manufacturer guidanceCertain options may affect the availability of other options and the performance levels. Consult manufacturer for details. |
Glazing bead | Standard. Pencil round. Ovolo. Manufacturer guidanceAvailable with standard or flush connections. |
FSC timber | FSC Chain of Custody. |
Handles | Handle/ pull - patio. Guidance for specification option: In/ out. Handle/ pull - modern. Guidance for specification option: In/ out. Handle/ pull - custom. Guidance for specification option: In/ out. Handle/ handle - patio. Guidance for specification option: In/ out. Handle/ handle - modern. Guidance for specification option: In/ out. Handle/ handle - custom. Guidance for specification option: In/ out. Manufacturer guidanceA range of handle heights and furniture colours are available. Consult manufacturer for details and insert requirements. |
Locking | Cylinder thumb. Cylinder key. Manufacturer guidanceKeyed alike options also available. |
Sustainability data
Country of product manufacture | United Kingdom |
Manufacturing plant location | |
Material | Timber Glass Wood |
