Tyde 6L Cistern with Lever
Verified by manufacturer 5 months ago
CIST102 - Dimple Style
CIST102 - Dimple Style
Dual flush lever cistern.
Application
Compatible with all SanCeram back to wall and wall hung WCs.
Description
Concealed dual flush lever cistern with standard or dimple style lever.
Features and benefits:
- Effective flush volume of 3.75 litre from a 6/3 litre dual flush.
- Delivers reduced flush when lever is held down and full flush when lever is depressed and released.
- External overflow warning.
- Top access.
- WRAS approved syphon and inlet valve.
- Lever can be cut to length to suit installation depths between 12 and 145 mm.
- Levers are fitted with vandal-resistant stops to prevent lever being rotated backwards.
- Manufactured under BS EN IS0 9001 and BS EN ISO 14001.
- Approved by the European Water Label Scheme.
General information
Color | Silver |
Material | High density polystyrene |
Shape | Other |
Length | 146 mm |
Width | 505 mm |
Height | 285 mm |
Warranty description | Five year |
Uniclass | |
CAWS | N13/15 Urinals and cisterns N13/75 Installing cisterns N13/300 WCs and cisterns |
Specification data - WC cisterns
Standard | To BS EN IS0 9001 and BS EN ISO 14001. |
Approvals | European Water Label Scheme and Water Regulations Approval Scheme (WRAS)-approved. |
Form | Concealed. |
Operation | Lever handle. |
Materials | |
Body | High density polystyrene. |
Capacity | 6/3 L dual flush. |
Water supply, overflow and outlet holes | |
Water supply | Side inlet. |
Outlet | Bottom outlet. |
Integral accessories | 457 x 305 mm flush pipe.Guidance for specification option: Supplied with. |
Handle type | Dimple style. |
Fixings | Once piece hanging bracket. |
