Type G200 framed glass sliding partition

Name: Type G200 framed glass sliding partition
Brand: London Wall Design Ltd
SKU: nXZgtYAA6QBaRbWjcAsmUi

Verified by manufacturer 6 months ago

Third party certifications:

Acoustic, glazed folding partition. Bi-fold doors, glazed partitioning, movable acoustic glazed partition, room divider, glass sliding partition

Jump to:

Application

Suitable for use as an acoustic, glazed folding partition.

Acoustic, glazed folding partition.

Features and benefits:

Color	Black White Manufacturer guidance White and Black as standard. Other RAL colour choices available
Finish	Coated
Material	Aluminium Glass
Shape	Rectangle
Length	Bespoke
Width	Bespoke
Height	Bespoke
Warranty description	Two year

Uniclass	Pr_25_71_57_80 Sliding stacking panel partitionsPrimary
CAWS	K30/76 Glazing for relocatable partitions K30/480 Glazing for relocatable partitions L20/545 Sliding stacking panel partitions

Third party accreditation	Swedish National Testing and Research Institute: Acoustic test to EN ISO 10140-2.
Performance	Rw 47 dB. Guidance for specification option: Measured in accordance with BS EN ISO 10140-2.
Operation	Manual. Guidance for specification option: Each alternate panel contains an integral shoot bolt mechanism operated at a convenient height from the floor. Leading pass door panel included as standard.
Dimensions (nominal)	-
Panel (average)	-
Width	Guidance for specification option: Up to 950 mm. Insert requirements.
Height	Guidance for specification option: Up to 3000 mm (maximum). Insert requirements. Taller panels possible to special order.
Thickness	Double-glazed 8.8 mm laminated with 59 mm internal air gap.
Average panel weight	-
Standard panel	40 kg/m².
Panels	-
Construction	Manufacturer standard. Low iron glass.

Ceiling track finish	Black. White. Satin anodized aluminium. Other RAL colour. Guidance for specification option: Insert requirements.
Frame finish	Black anodized aluminium. Natural anodized aluminium. Powder-coated, RAL. Guidance for specification option: Insert requirements. White powder-coated.
Floor Track	Satin anodized aluminium. Manufacturer guidance Finish.
Stacking layout	Centrefold bi-parting. Centrefold single unit. Endfold bi-parting. Endfold single unit.
Partition assembly	As per manufacturer drawings SL - 210 and SL - 211.

Contains Red List materials	No
Country of material origin	Sweden
Country of product manufacture	Sweden
Material	Aluminium Glass
Recyclability	Metal parts can be separated and directed to material recycling. Theoretically, particle board can also be recycled by directing the panels to new production
