HMS Victory - plank gratings

HMS Victory - plank gratings

Elefant Gratings T/A PcP Gratings Ltd

HMS Victory, situated in Portsmouth Historic Dockyard, is best known for her role in the Battle of Trafalgar; HMS Victory currently has a dual role as the Flagship of the First Sea Lord and as a living museum to the Georgian Navy. She transferred to The National Museum of the Royal Navy in 2012.A new Under Hull Walkway providing visitors to Portsmouth Historic Dockyard with the ability to walk beneath HMS VictoryVisitors are now also able to experience the HMS Victory Under Hull Walkway. The new walkway will enable visitors to safely descend into the dry dock base and view the 3600-tonne ship from below.Project criteriaThe under-hull walkway required new access walkways, landings, and stairs for visitors to visit this ship area. Therefore, it was essential to provide a safe solution that met but exceeded the criteria for public access walkways, treads & landings while also meeting the design brief.The solutionThe solution constituted a complete solution consisting of OPTIMO O5-M treads, landings & walkways. The combination of the choice of product and material provides excellent slip resistance, multi-directional, stiletto proof, walking stick proof, DDA compliant colour contrasting Nosings, self-draining & strength to weight ratio.The project success was determined by close collaboration with the partner, discussing product capabilities, loading criteria, etc., working closely with our technical sales & drawing office. This enabled them to detail/design their support steelwork to suit, saving them detailing time & money on unnecessary support/steel.Additionally, PcP was involved with product development & design assistance to supply a suitable safe solution to the brief.The resultMore than 150m2 walkways/landings plus stair treads with DDA compliant Nosings for public access at HMS Victory.
Sponsored
Auckland Castle Visitor Centre - gratings

Auckland Castle Visitor Centre - gratings

Elefant Gratings T/A PcP Gratings Ltd

Auckland Castle is just one of the many charming attractions of the Auckland project. The castle is one of the best-preserved bishops’ palaces in the whole of Europe and is at the centre of the Auckland Project. It is based in North England, showcasing fragments of a medieval castle discovered during recent archaeological digs, open to the general public.The project criteria The reconstruction of Auckland Castle required new access walkways, landings and stairs for visitors to be able to access the top, where they can experience stunning views across the town. For this purpose, it was essential to provide a very safe solution that responded to the strict criteria for public access walkways, while also meeting the prescribed design criteria to match the architectural milieu and building. Safe, Practical, Architectural steel walkwaysEven though the stairs, walkways and landings’ primary function is to provide safety for users to wander around Auckland Castle at height, the architects had unique requirements for the design. The solution had to fit perfectly with the rest of the construction with the following prescribed:High quality finish tailored to project requirements and matching the building type and architecture The gratings and treads had to allow natural light to penetrate through, owing to the size and shape of the buildingMaintaining a high level of slip resistance and loading capacity in accordance with relevant British Standards The solutionIn close collaboration among the contractor, architect and PcP, a bespoke solution was designed consisting of a special nosing solution to enable installation off aftermarket nosing, whilst relying on the integrity of the close PcP MESH™ tread.Additionally, slip-resistant requirements were addressed by reducing slip and fall risk to enhance slip-resistance.Utilising our experienced in house drawing office, we initially provided general layout drawings and ultimately panel drawings for client approval, to ensure all items were correct, with any specific site considerations being accounted for.
Sponsored
Stauning Whisky’s distillery - gratings

Stauning Whisky’s distillery - gratings

Elefant Gratings T/A PcP Gratings Ltd

A dream comes trueIt all started in 2006 when nine whisky enthusiasts sat down together to devise a plan for realising their dream of transforming their whisky-making hobby in a primitive old slaughterhouse into a new and modern Danish whisky distillery. In 2007, the dream soon became a reality when the project took off in earnest, and the plans were for building the modern distillery, Stauning Whisky, were launched.The ProjectStauning Whisky dreamed of creating a modern distillery where they could make real whisky. Stauning Whiskey chose PcP to provide mesh gratings for the platforms and mezzanine floors, as well as ventilation gratings for the drying halls. Before building work started, construction meetings were held with the building’s owners as well as the architect, consulting engineer and the smith.Design requirementsAs the designated supplier of mesh gratings for the distillery’s platforms, PcP’s specialists advised on the choice of product, solution, material, load and safety requirements and matched the desired criteria from Stauning Whisky. When PcP provides advice, it is important to ensure that the solution meets all the requirements regarding load and safety as well as the customer’s design requirements. Stauning Whisky was very keen that the solution would visually match the rest of the distillery. At construction meetings, all the parties agreed on the best solution, which also took into account Stauning Whisky’s design requirements.Safety requirementsThe height of the distillery was set at 3.2 metres, so safety was a key factor for employees as well as visitors. Therefore, a mesh gratings solution was chosen, which was intended to look like a solid floor.The SolutionIn close cooperation with Stauning Whisky, the architects, engineers and smiths, a unique solution was arrived at which aesthetically complemented the desired visual look while optimising the sense of safety at the height of approx. 3.2 metres. PcP supplied a customised solution with press-locked mesh gratings and steps with cut-outs for copper pipes.Unique designThe mesh gratings were designed and manufactured according to the customer’s wishes and design requirements.PcP tailored the galvanised steel mesh gratings to create a 1,000-square-metre platform and mezzanine level in the distillery, where the whisky is produced in copper pot stills. The combination of different metal types ensured a modern design while at the same time creating an authentic experience of a real whisky distillery for visitors to Stauning Whisky.The galvanised steel platform had to be integrated with the copper still pots in the distillery, while the mesh gratings needed to comply with special mesh size requirements.Unique cut-outs with manual weldsThe PCP mesh gratings are precisely tailored to the distillery. The platform solution comprises mesh gratings which are developed and produced by PcP’s experienced product developers and technical draftsmen. The detailing was carefully executed by PcP’s welders, who made unique cut-outs and manual welds. The bearing bars for the gratings were placed in the opposite direction than standard, and the crossbars were higher than normal. This created a visual impression of a solid steel platform, providing a sense of security for both employees and visitors when moving about at the height of 3.2 metres.Optimum safety and aesthetic designIn close cooperation with Stauning Whisky’s project employees for the building work, effective decisions were arrived at for a unique solution. PcP was responsible for supplying a modern and robust solution with fine details that fully lived up to the customer’s wishes. In addition to its very high strength, the steel platform provides a sense of safety and security for employees and visitors to the distillery.
Sponsored
JK House - gratings

JK House - gratings

Elefant Gratings T/A PcP Gratings Ltd

The JK House project is a privately initiated development of a villa in the Bezuidenhout area of The Hague. The architect responsible for this project is Jacco van Wengerden from Atelier van Wengerden, located in Amsterdam. The unusual location of the site, surrounded by buildings erected in the 1930s, required balanced choices in the materials used for the façade. Furthermore, the villa's design needed to meet the conservative demands of the local aesthetics committee The Hague municipality and tying in with the adjacent buildings. The architect, Van Wengerden, immediately realised the potential of the site. By making the right choice of materials for the façade, he could refer to the former garden centre on this location and the colour and structure of the brickwork of the adjacent buildings. The SolutionIn his quest to find the right materials for JK House’s unique façade, Van Wengerden decided to use COR-TEN steel MESH® gratings in his design. Although these gratings are originally designed for industrial flooring, this particular choice of material would solve several issues at once. Firstly, COR-TEN steel gratings are relatively affordable. Secondly, they fit perfectly into the existing surroundings and refer to the site's past. The local aesthetics committee of The Hague municipality was pleased with the choice of this material. Especially by the fact that a COR-TEN steel façade was perfect for allowing vegetation to grow on, which is another reference to the history of the site. Trying to find a supplier for this façade, Van Wengerden approached PCP's local office in the Netherlands. Since PcP could produce these gratings in a wide variety of dimensions in both bearing and filler bars, Van Wengerden could design the gratings to match his initial idea of vertical lines in the appearance of the façade.For a more vivid look, PcP produced gratings with dimensions between the vertical bearing bars of both 44 and 55mm, where the filler bars were spaced 150mm in between. In addition, the gratings were mounted backwards, leaving only the bearing bars visible. Despite making production more challenging, the desire was also to have no edge bars on the top side of the gratings for a more open appearance, and PcP was able to deliver this. The result is a Villa with a façade that, in time, due to the natural process of the rust-brown colouring of the COR-TEN steel, will be at one with its surrounding buildings. The Collaboration The first contact about the project was established in early 2015. Over a period of several years, Van Wengerden and PcP discussed options and difficulties in manufacturing the façade. After making design choices, we produced samples to visualise the choice of mesh sizes and discolouration of the COR-TEN steel. We completed the project at the beginning of 2019.
Sponsored
Backstage ² Upkot student flats - gratings

Backstage ² Upkot student flats - gratings

Elefant Gratings T/A PcP Gratings Ltd

The ancient printing house of “De Vooruit” in the Center of Ghent, was completely stripped to only the ancient concrete supporting structure. From there the renovation to an ultramodern student home was to be made with steel, providing safe stairways, safe and easy to walk on platforms, as well as outside sitting areas for the students. This was all to be made in aesthetical harmony with other products, such as COR-TEN steel that was used in the project. This to create a modern look, aspiring to the students.The project criteriaPcP had to meet the criteria for a sustainable, durable product which was safe and comfortable to walk on. At the same time, the product needed to blend in well with the COR-TEN steel being used for other parts of the project, providing a modern look that would appeal to students. Another challenge was installing the new steel structure onto the existing concrete supporting structure of the original building.The solutionLannoo Konstruktie chose the OPTIMO® O2, Spiral treads – Type K and panels, as these high-quality products met all the stated requirements for the new student accommodation building. In addition, it was a bonus that the OPTIMO® O2 perforation is easy to walk on in all types of shoes, and is even suitable for outdoor furniture, such as tables and lounge chairs.“The strength-to-weight ratio of the PcP solution is very favourable. This was very helpful for us, as we had to mount the new steel structure onto the old concrete supporting beams. It was important to have a light but very strong panel and steps. PcP was ideal for this purpose.”– Christophe Lannoo, CEO, Lannoo KonstruktieThe resultThe ancient printing house of ‘Dagblad Vooruit’ in the centre of Ghent was completely stripped back to its concrete supporting structure. The structure was then developed to create ultramodern student accommodation using steel with safe stairways, safe and comfortable platforms as well as exterior seating areas for students. This work all harmonised aesthetically with the other building materials, such as the COR-TEN steel used in the project. The aim was to create a modern and inspiring student residence.Architectural steel platform and spiral stair treadsThe project lasted a total of five months from first production to final installation of the panels and steps. In total, 150 spiral K treads were used for three spiral stairs on the three-storey building. More than 100 OPTIMO® O2 treads were installed, together with almost 300 square metres of OPTIMO® O2 panels, both standard and customised. For Lannoo Konstruktie, it was a very attractive project to be engaged in, and likewise for PcP, which is used to projects which are more industrial in nature.
Sponsored
Heathrow Park maintenance walkway - plank gratings

Heathrow Park maintenance walkway - plank gratings

Elefant Gratings T/A PcP Gratings Ltd

Heathrow Park is an industrial estate situated close to Heathrow Airport, UK. The construction project involved different collaboration partners – a UK steelwork and installation company and a main contractor, both operating as key stakeholders in the Heathrow Park project. The steelwork company contacted PcP on behalf of the main contractor, looking for a cost-efficient steel maintenance roof walkway to access roof equipment.Project criteria and proposalOn behalf of the main contractor, a steelwork contractor approached PcP to quote for a suitable product for 3,260 square metres of steel flooring for a maintenance walkway. Normally, twisted bar grating is specified for projects of this kind, but PcP CUBE® gratings were suggested to match the customer’s criteria regarding delivery time.The main contractor required grating for a steel flooring platform which had to be supplied by a very tight deadline and at a competitive price but with a high-quality finish. Once the customer accepted the initial proposal for the CUBE® gratings, PcP ensured that the quotation met the all the criteria specified by the client for the planning application. We provided Static load calculations and samples in order to obtain final approval.The solution CUBE® grating – an alternative to twisted bar gratingPcP proposed the new B-CUBE® grating for Heathrow Park flooring as it could be made to suit the spans required at a competitive price. However, and more importantly, the B-CUBE® grating proved a viable proposition to the client due to the low weight of the product compared to other gratings. The delivery time also met the strict site requirements. For the project, the B-CUBE® grating was manufactured over a six-week period using robotic welding on both day and night shifts in order to meet the project schedule.PcP experts delivered tailor-made CUBE® gratings for the steel flooring, and the work included paying special attention to details, accurate technical drawings, and providing all the necessary product certification and datasheets.Customer support, technical expertise and calculationsIn order to address any queries, PcP provided full support from its technical department and customer service team. The following elements were relevant for meeting the strict requirements to both product and delivery:PcP in-house calculation software and expertise was used to provide the know-how required to produce specifications and data sheets in line with British Standards and to meet customer requirements.PcP’s experienced in-house drawing team provided full panel drawings for client approval prior to manufacture.
Sponsored
Hising Bridge - plank gratings

Hising Bridge - plank gratings

Elefant Gratings T/A PcP Gratings Ltd

The Hising Bridge is to become the new landmark of Gothenburg. Spanning over the central part of Scandinavia’s most significant commercial harbour, The Hissing Bridge will replace the existing Göta River Bridge from 1939.Aesthetically, the Hising bridge will become ‘a street’ within the city, for people to walk on and below and, to enjoy spectacular views. The Hising bridge will bind the Göta River shores for cars, busses, trams, pedestrians, and bicycles.The Hising Bridge project involves many partners, entrepreneurs, and subcontractors. PcP was involved in the project to design and supply safety solutions for access walkways, platforms, stairs, and architectural ceilings. The new bridge is approximately 440 metres long.Project criteriaThe construction work for the Hising Bridge began in 2013 and will replace the old worn-out bridge from 1939. The project involves a range of highly experienced partners within construction and infrastructure: Trafikværket and Skanska, to name a few. The project prescribed stainless steel gratings to decorate the bridge with an architectural ceiling that would blend into the atmosphere and surroundings. The purpose is to give people an unforgettable experience of the architecture and the bridge lights during the day and on a “special” night.The criteria for the ceiling of stainless-steel gratings were prescribed in the project to fulfil an aesthetic design as a ceiling and at the same time provide a functional safety platform for maintenance workers.Additionally, the project had prescribed the need for safe access walkways, stairs, and service platforms to ensure maximum safety for workers on the entire bridge.SolutionThe project partners chose PcP to provide the complete solution: ceiling, stairs, walkways, and service platforms.The different applications involved close collaboration between the partners throughout design, development, test and delivery. The range of applications was a thorough process of designing, drawing and technical advice. The entire solution involved PcP products from OPTIMO, CUBE and Guardrail.CUBE® as architectural ceiling1000 m2 CUBE® gratings decorate the ceiling below the bridge with a multifunctional purpose combining design and functionality. The unique design is simplistic and efficient and provides excellent light penetration at night.
Sponsored
Blue Buoy stairway, Porthleven - gratings

Blue Buoy stairway, Porthleven - gratings

Elefant Gratings T/A PcP Gratings Ltd

Cornwall County Council was responsible for upgrading and renovating an existing stairway to Blue Buoy Beach at Porthleven. A specification and sample were given to the Council, who approached three different fabricators/installers, all of whom came to PcP for an engineered safety solution on treads/landings.Insteel Industries is one of the largest architectural fabricators in the county of Cornwall. Insteel successfully won the contract to supply and install, In looking for the right partner who could offer loading criteria and technical information that complied with the relevant standards.Project criteriaThe Blue Buoy stairway project specification initially requested stainless steel and open-mesh with an alternative for a “Heel-proof version with a 20mm gap and a durbar plate for a slip-resistant surface.The SolutionPcP proposed a galvanised alternative instead of stainless steel but 140 microns and anti-slip nosing for a slip-resistant surface. The proposed solution was cost-effective, safe, durable and matching budget criteria.PcP proposed the 05m nosing as it has a much better slip-resistant on the front edge. In addition, PcP suggested a 33/8 mm pattern would be more suitable for heels than a 20mm gap.Insteel Industry forwarded a drawing/specification sheet to Cornwall Council, who then accepted the 33/8 mm pattern. However, there were concerns that we couldn’t offer 140 microns with our 2/3mm bars.PcP provided a sample that was Shotblast before galvanising with six localised readings of coating thicknesses. Insteel Industries presented the product sample to the council architect for final approval.The resultThe stairways are suitable for access with all types of footwear and pets also to access the beach. The 05m nosing on the treads comply with the slip-resistance recommendations of Bs7976 which are a superior alternative to the durbar plate initially specified. Shotblasting offered an increase in the thickness of galvanizing treatment and enhanced corrosion resistance, providing a more durable product. Perforated rear riser allows water to pass through when storms and high waves hit the staircase.
Sponsored
Major sports retailer in Oxford Street, London - gratings

Major sports retailer in Oxford Street, London - gratings

Elefant Gratings T/A PcP Gratings Ltd

A unique Ridgeway project required modern balustrade infill panels for a brand-new four-storey flagship sports retailer store in Oxford Street, London.Ridgeway chose PcP gratings for this project as they knew they would receive the professional service required to complete this project on time without compromising on quality. The mesh gratings complied with requirements governing bar alignment.A modern architectural solution with a perfect finish including bar alignment where appropriate was manufactured, and fabrication drawings within all tolerances provided.About RidgewayRidgeway is a large stockist and supplier to main contractors in both Ireland, where the company is based, and the UK. Ridgeway is also a renowned customer-oriented supplier of innovative construction solutions.The criteriaAfter having worked as a trusted partner with PcP for various construction projects, it was easy for Ridgeway to find the right company to supply balustrade and infill panels.Ridgeway required fast delivery to meet their project schedule without any comprises being made to the quality of the finished product combined with close technical support, including product technical information, data sheets and material certifications.To meet the strict requirements for dimensions and bar alignment, PcP provided relevant technical information and a product data specification proposal which complied with relevant standards.The solutionRidgeway chose PcP’s MESH gratings for panel infills in galvanised steel to complete the staircase systems on all four storeys in the store. The alternative solution proposed by PcP exceeded quality expectations and was tailor-made with a flawless finish and customised cut-outs to match the design. The product was developed and manufactured to meet Ridgeway’s project schedule and included suitable fixings.PcP exceeded project requirements and expectations as regards both value and aesthetics, including the supply of ready-to-install panels and fabrication drawings which took into consideration bar alignment, cut-outs and suitable fixings where appropriate. Collaborating with PcP supports Ridgeway’s goal of delivering quality construction solutions on time.Technical supportDuring the entire collaboration – from product development to delivery – Ridgeway received ongoing technical support from PcP’s local experts based in Ireland who functioned as a first point of contact for assisting with any queries that Ridgeway had during the project.In addition, PcP’s internal and external staff ensured that samples, technical info, data sheets, company certificates etc. were supplied as required.On receipt of the order, full fabrication drawings were provided which took into account tolerances and bar alignment, including raked panels and notches where required.
Sponsored
New Air BP Jet Fuel Station - plank gratings

New Air BP Jet Fuel Station - plank gratings

Elefant Gratings T/A PcP Gratings Ltd

This project involves the partners Fremek AB, Totech AB and PCP A/S.Fremek is a workshop company in Dals-Långed that is certified according to EN-1090, EXC1, EXC2 and EXC3. Fremek specializes in welding, cutting, painting and assembly of large projects throughout Sweden.PcP’s solution includes CUBE® gratings and treads for a modern design and ladder systems for worker safety. Fremek and Totech chose PcP’s solution to install a new fuel station for Air BP, one of the world’s largest aviation suppliers.Project criteria - Slip-resistant steel platformFor this project, Air BP required an anti-slip platform due to the use of oil during maintenance.Although the platform is new construction, it was erected on an existing outdoor structure with nothing but a roof and fuel tanks. Thus, there were specific dimensions required.Therefore, PcP provided a more efficient fuel station platform and a safe working environment for personnel carrying out aircraft maintenance.The project had a strict timeline of 10 weeks as the construction had to be finalised before winter.Fremek was responsible for designing the air-plane fuel station and for sourcing the correct materials. Fremek contracted Totech for the works. Totech has more than 25 years of experience managing complex projects for a range of industries and, therefore, extensive knowledge of industrial construction and of which materials to use.PcP has delivered gratings to Fremek in several previous projects. Totech, therefore, approached PcP to showcase gratings with high slip-resistance for the platform. Totech seeked to use standard sizes to meet customer requirements of lead time and budget. At this point, Totech discovered that PCP also could provide handrail and ladder systems.Project solution - CUBE gratingsThe PcP CUBE® gratings, treads and toe-plate were provided for the platform in standard sizes. For easy access to the platform, PcP provided fire escape ladders and safety handrails. PcP CUBE® gratings and treads benefit from outstanding high PTV slip-resistance reducing trip and fall risk, lightweight but strong and fitted perfectly into the existing construction from the ground to roof.Fremek installed the platform, and the workers on-site made cut-outs to suit various plant equipment. Additionally, PcP provided escape ladders to mount on fuel tanks. In case of fire incidents/emergencies, enabling workers to escape rapidly.
Sponsored
Waterplein Revaleiland Amsterdam - gratings

Waterplein Revaleiland Amsterdam - gratings

Elefant Gratings T/A PcP Gratings Ltd

The Waterplein Revaleiland Amsterdam project was constructed by the contractor Knipscheer Infrastructuur BV, a medium-sized construction company specialising in infrastructure (roads, bridges etc.). With about 120 employees, Knipscheer carries out civil engineering work in the Netherlands.The criteriaAs the contractor, Knipscheer’s role was to construct a new and modern square for use by the general public at Waterplein Revaleiland. The project to build a pier presented challenges because the design criteria specified a wooden pier to match the existing environment. High safety standards and a modern design were the ultimate criteria for constructing the pier. Knipscheer chose PcP as a partner to supply the gratings for creating the wooden pier, with wood planks being installed into the gratings to create a perfectly straight line the full breadth of the structure. In such cases, steel beams are often used as a substrate for wooden planks, but this requires large quantities of steel and results in higher costs, and therefore mesh gratings were chosen for this project.The solutionTo create the new public square at Amsterdam Waterplein Revaleiland comprising one large wooden pier, Knipscheer chose PcP to supply 1,400 square metres of press-welded gratings. The mesh gratings are placed upside down on a concrete surface to ensure the wooden planks are stable.Each press-welded grating is tailormade to meet the specific dimensions, with a mesh size of 111 x 99/60 x 3 mm. Customised mesh sizes can only be made with a press-welded grating, and therefore this option was optimal for this particular project. The gratings were placed upside down on the concrete. Knipscheer then laid 28 mm thick hardwood planks into the gratings. The challenge here was to draw and produce mesh sizes in one line, so the wooden planks in each grating could meet the visual design criteria of appearing to be continuous wooden planks extending the full width of the pier.The collaborationThe collaboration with the contractor Knipscheer commenced in 2018. PcP worked close with the contractor throughout the entire project to meet the design and technical criteria of both Knipscheer and the client. Drawings and samples were supplied by PcP, Approved by the contractor’s customer.
Sponsored
WUM Urban Outdoor Furniture - gratings

WUM Urban Outdoor Furniture - gratings

Elefant Gratings T/A PcP Gratings Ltd

An unconventional idea from a Constructing Architect and former Officer becomes unique design furniture under the Danish designer brand WUM. The furniture collection Urban Outdoor is based on very traditional PcP gratings, usually used, i.e. industrial and construction sectors, where very high strength is needed.About WUMWUM is a Danish designer brand and, in fact, short for "WoodUmix". In 2018, the journey started for Marius Øvrum and Peter Wallbohm Olsen - the partners behind the design company - with the explicit goal of designing and producing lamps and furniture in Denmark. WUM's designs must stand out from the market, and the focus of the concept is to offer products that are both designed, developed and produced in Denmark and could still be provided at competitive prices. WUM has taken the first step with garden furniture sets made in classic and Danish PcP mesh gratings.With Danish production and development, this means that WUM will achieve a sustainable mindset..." It fits our moral compass, and we like the mentality of trying to create sustainable and responsible products", explains Peter Wallbohm Olson, co-owner of WUM.Project criteriaWUM's approach to design projects involves close collaboration with all partners. For example, for the development of garden furniture, the idea of using mesh gratings was already in place. WUM, together with PcP, has developed the requirements for the design project based on the knowledge and experience of PcP. Both in terms of designing a beautiful and durable product as well as keeping costs down."That's very much how we think and work. So how can we create an exciting, new and different design product that we can offer at an attractive price for customers? Here, refining and processing classic industrial components is an obvious option", says Peter Wallbohm Olsen.There was a significant focus on product design; how could you transform a traditional mesh grating to look like a real bench and a table? The criteria of appealing and unique design, durability and easy to produce were the focal point of the cooperation with PcP.Solution and manufacturingTogether with PcP, WUM has developed prototypes for garden furniture. The gratings are made in bespoke dimensions for outdoor tables and benches in three different sizes (Small, Medium and Large).The garden furniture is made of 33/33 mill finish steel mesh gratings with 25/2 bearing bars. Instead of 25x3mm edge bars most commonly used, they are made with 25x5mm edge bars. This solution reduces the deflection of the garden furniture as much as possible. In addition, mounting holes are made in the grates to suit WUM's mounting brackets. Finally, the gratings get an extra-fine finish in the form of sharp edge grinding and welding spray. Once manufactured by PcP, they are sent for surface treatment: electropolish and then powder coating. As a result, the material and construction of garden furniture is a very durable solution for both weather conditions and capacity.
Sponsored
The German museum Villa Wippermann - plank gratings

The German museum Villa Wippermann - plank gratings

Elefant Gratings T/A PcP Gratings Ltd

Villa Wippermann in Halver, Germany is an old factory owner’s beautiful villa, originally belonging to the Wippermann family, built back in 1892. The old villa was renovated to serve as a regional museum and a cultural meeting place. The fire protection and heritage conservation requirements, in particular, presented a demanding challenge to the planners of the escape routes and escape staircases. Space-saving design was required, while creating a staircase system without any additional connection to the building (no transfer of forces into the historical building structure). The architectural appearance of the building also had to be preserved in the best possible way, and safe use by visitors had to be guaranteed in the event of an emergency.The criteriaThe client, City of Halver, involved experts, architects and engineers in the make-over of the museum. The project had a significant focus on safety in case of fire or other events that need safe evacuation. The parties involved required a spiral staircase as a fire escape solution, to be installed without causing any damage to the building.Minimum strainThe engineer and architect were both very aware of the fact that various environmental conditions such as wind and vibrations can cause too much load, leading to damage to the building.DesignAs stated in the project criteria, the architectural heritage of the building had to be preserved. This called for a safe but well-designed spiral staircase, fitting into the environment and to the unique architecture of the building and maintaining the appealing aesthetics of the Villa Wippermann museum.The solutionBased on these project criteria, PcP delivered a proposal that presented a safe and secure spiral staircase for the museum. The project architects and the planners from the building and heritage authorities accepted the proposal.Spiral staircase made of galvanised steelA complete spiral staircase system was designed and tailor-made to support the unique criteria of the project. A large steel pipe at the centre of the staircase provided solid support to the entire structure. A slim handrail system followed the spiral shape of the staircase. All details and products were made of galvanised steel, matching the architectural and aesthetical look of the building. The staircase links the historical building together with modern architecture.The staircase was designed by PcP and manufactured using modern industrial production methods, combined with handmade finishes and details.OPTIMO® steel treads and gratingsThe PcP OPTIMO® O3 spiral treads and gratings were used for treads and landings, providing safety in terms of optimal slip resistance, capacity and fire proofing. The high and certified slip resistance according to evaluation group R13/V10 and the limited views below allow even people with a fear of heights to walk safely. The surface of OPTIMO® O3 flooring delivers the very best drainage of liquids.The resultAs a result of the strong collaboration between architects, structural engineers and planners from heritage protection and fire protection, a safe, solid and aesthetically pleasing spiral staircase now compliments the museum.Today, Villa Wippermann museum stands as a harmonious building with a perfect balance between modern and old architecture in beautiful surroundings.
Sponsored
Safe aluminium ramps

Safe aluminium ramps

Elefant Gratings T/A PcP Gratings Ltd

Lambertsson is one of Scandinavia’s largest rental companies and service providers in construction and industrial solutions. Lambertsson erects cranes and elevators for construction projects, among other activities. Shorter building times, better control over costs and smoother processes are therefore critical and beneficial to the project owners.ChallengeLambertsson has been erecting and dismantling elevators for more than a decade using wooden planks or plywood for building the elevator ramps. This method of building ramps is time consuming and resource demanding. Lambertsson needed a simple ramp solution that would make the project planning time more predictable and less time consuming when erecting the elevators. Lambertsson needed a ramp that could handle the same weight as the elevator, equivalent to a capacity of 2.1 tonnes, and without exceeding 1.3 metres from the position .SolutionIn order to meet the criteria of Lambertsson, PcP Scaffolding developed a custom solution based on the PcP OPTIMO® grating series, which is the safest choice for applications in construction, where workers are on the job. To customise a simple solution, PcP built a ramp that is able to lift the same capacity as the elevators, up to 2.1 tonnes, with a span of 80 cm. The ramp is made of aluminium decks and is very light to install.
Sponsored
Platforms and stairs for grandstand systems - plank gratings

Platforms and stairs for grandstand systems - plank gratings

Elefant Gratings T/A PcP Gratings Ltd

The task was to replace old wooden floor planks with modern, robust, weatherproof and slip-resistant steel flooring and stair treads that met all the customer’s requirements pertaining to load. In particular, the customer was keen to reduce the strain on workers during both dismantling and assembly. Furthermore, it was also necessary to reduce the noise pollution which occurred when working with metal against metal.The solutionIn cooperation with our customer, the customer’s assembly teams and our product development department, solutions were developed that met the above requirements.User safetyOne of the main challenges which had to be addressed in the customer specification was the requirement for a slip-resistant surface. Here we were able to incorporate a surface design based on our PcP OPTIMO® O2 surface, which has already been used for a wide range of projects worldwide. OPTIMO® O2 is certified according to R13/V10 slip-resistance and meets the strict demands to slip-resistance. OPTIMO® O2 grating discreetly improves safety for visitors during an event while also improving handling for the installation team.With a very small surface perforation of only Ø 5/9 mm, people frightened of heights are unable to look down directly through the platform on which they are standing, thereby guaranteeing a sense of security. Furthermore, this profiling solution offers perfect drainage, ensuring that the floors always remain dry.Combining aluminium and steel – a lightweight solutionFor the system flooring, a combination of aluminium and hot-dip galvanised steel was chosen to reduce weight without compromising capacity. For example, the gratings used for floors and treads were supplied in aluminium and screwed together with high-strength steel end pieces to form a complete unit. This reduced the weight of the components, and provided a significant ergonomic advantage compared to the wooden planks which had been used to date.Reducing noise pollutionDespite the considerable weight reduction from using individual components, another challenge presented itself. Some of the treads and platforms on the metal substructure produced considerable rattling noises. However, even this challenge was overcome with a slightly unconventional method. By installing small oak blocks in the steel end pieces, the fixing points were tightened on the substructure, which significantly reduced the rattling noises.The resultThe customised solution combined steel and aluminium PcP products to provide extremely safe gratings for system floors and stairs for mobile and stationary grandstands. The solution is more ergonomic, lighter and meets the high requirements for safety and load bearing.Furthermore, it meets the overall objective of ensuring safe events for visitors. A successful event relies on the successful implementation of grandstand systems.
Sponsored
Aluminium work platforms for industrial tipper trailers

Aluminium work platforms for industrial tipper trailers

Elefant Gratings T/A PcP Gratings Ltd

The project was to provide an existing system with the new solution that offers high slip resistance according to evaluation group R13/V10* and to make it processable for a series production. For the new work platform on the trailers, a high-quality standard was to be achieved.The task included strict criteria for using recyclable metal with a minimum of waste without compromising with quality. Furthermore, the platform solution needed to achieve a very high standard in terms of quality with an outstanding finish and dimensional accuracy. outstanding surface finish and dimensional accuracy.The solutionAluminium floors for tipper work platforms “From coil to finished product”Optimal production technology in combination with high-performance materials enables production "from the coil to finished product" in terms of reproducible quality / extremely high dimensional accuracy / a perfect surface finish and economical production.In cooperation with our customer and our suppliers in the field of material and surface protection, we have developed a solution that allows us to develop an aluminium floor for the working platform on our customer's tipper trailer, true to our motto of manufacturing "from the coil to finished product".Due to our production technology of a sequence of several processing steps on a production line, we were able to develop a new floor for the working platform on our customer's tipper trailer using surface profiling (PcP Safety Grating Type US), we were able to achieve the slip-resistance classification required by the customer and certification by the Institute for Occupational Safety and Health (IFA in Sankt Augustin) - according to evaluation group R13/V10. Furthermore, the tools and materials used have enabled the process accuracy and the processing speed to be optimized and improved to a large extent. In particular, the excellent cooperation with our material suppliers (special foils in order not to contaminate the tools with foil residues) enabled us to achieve a perfect surface finish as required by the customer. Further processing is therefore not necessary and minimizes operational ways and resources.Quality assurance of products and series productionDue to the process-guided production, only the slightest deviations from the specified dimensional and quality requirements are possible. These are monitored and documented by instructed personnel and employees trained in the area of quality at specified inspection intervals. In particular, the product test bench set up for this purpose enables our employees to carry out a comprehensive test on the component and immediately correct deviations in series production.The resultCustom made flooring meets the strictest safety criteria for tipper trailersDue to the partly optimized tool technologies and adapted or partly new procedures and processes, the requirements of our customer's specifications could be fulfilled to 100%. The requirements of the employers' liability insurance association and occupational health and safety could be achieved with a certification (IFA) according to slip resistance class R13/V10. This decisive requirement was accompanied by the demands for process-optimized series production while meeting the requirements for dimensional accuracy and perfect surface finish.As a result, we are confident that we can supply our customers with a product that lives up to their name and market position.
