AIRTRAK® PRV Pitched Roof Ventilator - Roof Ventilation System

Name: AIRTRAK® PRV Pitched Roof Ventilator - Roof Ventilation System
Brand: Nicholson STS Ltd
SKU: vKtdsFeVpYhZ43BjTRGuzX

Verified by manufacturer 9 days ago

Nicholson STS Ltd

Third party certifications:

ISO 9001 Quality Management
Certificate type

Provides point ventilation to lead roofs and vertical cladding where appropriate.

Jump to:

+44 (0) 1763 295828 Website

Application

Suitable for providing point ventilation for lead roofing and slated and tiled roofing on pitches over 30°.

Can also be used in slated and tiled roofs where a more traditional look is required. The ventilator should be welded to a larger base sheet prior to being included in the slating or tiling.

Description

Provides point ventilation to lead roofs and vertical cladding where appropriate. The traditional shape adopted is suitable for pitches of 30º and over.

Features and benefits:

Includes an integral stainless steel woven mesh fly screen.
The ventilator is positioned over a hole in the decking and lead covering and welded into position.
A storm check is incorporated into the design to guard against water ingress in extreme conditions.

General information

Material	Stainless steel Guidance for specification option: Insect mesh.
Length	260 mm
Height	98 mm
Warranty description	Ten year

Uniclass	Pr_30_59_29_82 Strip ventilatorsPrimary
CAWS	H71/110 Lead sheet fully supported roof covering H71/130 Lead sheet fully supported wall covering

Specification data - Strip ventilators

Purpose	Point ventilator for lead roofing and slated and tiled roofing on pitches over 30°.
Ventilation opening	3000 mm².
Colour	Grey.

Materials	Code 5 lead. Guidance for specification option: Ventilator. Manufacturer guidance Stainless steel insect mesh.

Sustainability data

Contains Red List materials	No
Country of material origin	United Kingdom
Country of product manufacture	United Kingdom
Material	Stainless steel Guidance for specification option: Insect mesh.
Recyclability	Recyclable at end of life
Recycled content As defined in clause 7.8 of BS EN ISO 14021	50 %
Expected Life	30 year
