Drinking Fountain - ANMX301
Verified by manufacturer over a year ago
Drinking fountain with bottle filler wall hung.
Application
Drinking fountains for wall mounting.
Description
Drinking fountain with bottle filler wall hung.
Features and Benefits:
- Supplied complete with bottle filler, bubbler, chlorine water filter.
- The wall mounted model is simply fixed to the wall using integral mounting brackets.
General information
Color | Silver |
Finish | Satin |
Material | Stainless steel Guidance for specification option: grade 1.4301 (304) |
Shape | Square Guidance for specification option: Rounded front. |
Length | 350 mm |
Width | 350 mm |
Height | 461 mm |
Warranty description | Five year Guidance for specification option: Two years for water controls. |
Uniclass | |
CAWS | N13/379 Drinking fountains |
Product range |
Specification data - Water coolers
Form | Wall mounted. |
Integral accessories | Spare chlorine water filter, spare bubbler. |
Product Reference | (ANMX301) 213.0000.025 (ANMX307) 213.0000.003 Guidance for specification option: With bottle filler. |
Sustainability data
Contains Red List materials | No |
Country of material origin | Poland |
Country of product manufacture | Poland |
Recyclability | Manufacturer guidanceRecyclable. |
BIM objects
NBS BIM Object Standard
This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.
Find out more about the NBS BIM Object Standard.
| Platform | Compatible | Version |
|---|---|---|
 Revit | - | 2 |
 IFC | - | 1 |
