Ecophon Super G™ A - Ceiling System

Name: Ecophon Super G™ A - Ceiling System
Brand: Saint-Gobain Ecophon
SKU: 8iGhydrBFhEoATSWgWvoLq

Verified by manufacturer 6 days ago

M199 Ecophon Super G™ A 20 mm

Product certifications:

Exposed ceiling grid system with acoustic tiles.

Jump to:

Application

Ceiling applications where there is a risk of mechanical impact, including school corridors.

Exposed ceiling grid system with acoustic tiles kept in place with impact bracing bars or clips.

Features and benefits:

Note: These tiles are non-demountable.

Color	White Guidance for specification option: NCS S 1002-Y. 78% light reflectance.
Finish	Primed Natural
Material	Glass Fibre
Shape	Rectangle Square
Length	600 mm 1200 mm
Width	600 mm
Height	20 mm 35 mm Manufacturer guidance 20/ 35 mm standard tile thickness. 200 mm standard overall depth of system. 50 mm minimum overall depth of system.
Warranty description	Ten year

Uniclass	Ss_30_25_22_51 Modular suspended ceiling systemsPrimary
CAWS	K40/265 Infill units K40/105 Suspended ceiling system K40/10 Unit/ modular suspended ceilings K40/115 Unit/ modular suspended ceiling system

Classification data
System performance	Acoustic performance
Ceiling support	Connect™ T24 grid.
Support fasteners	Connect™ adjustable hanger with Connect™ hanger clip. Connect™ hygiene clip.
Ceiling units	Ecophon Super G™ A - glass fibre infill units.
Barriers in ceiling void	-
Fire barriers	- Manufacturer guidance Insert requirements or omit.
Acoustic barriers	- Manufacturer guidance Insert requirements or omit.
Plenum barriers	- Manufacturer guidance Insert requirements or omit.
System accessories	- Manufacturer guidance Insert requirements or omit.
Installation	M199 - Suspended ceiling.
Indoor climate	Eurofins Indoor Air Comfort® Gold, French VOC A+.
Sound absorption	Class A to BS EN ISO 11654. Guidance for specification option: Noise reduction coefficient: 1.00 αw (Overall depth of system: 200 mm). Noise reduction coefficient: 0.95 αw (Overall depth of system: 50 mm).
Reaction to fire	To EN 13501-1, A2-s1,d0.
Size (length x width)	600 x 600 mm. 1200 x 600 mm.
Thickness	20 mm.
Trim	Connect™ channel trim 0532.
Weight	2.7 kg/m².
Standard	CE marked according to the European harmonized standard EN 13964.
Finish	White. Guidance for specification option: White 085. NCS S 1002-Y. 78% light reflectance.
Impact resistance	To EN 13964, 3A.

Material	Glass Fibre
A1–A3 ('Production stage')	Embodied carbon as defined in BS EN 15804
Normalized unit
Declared unit	3.28 kg CO₂ eq/m² Certified Lower emissions Guidance for specification option: A1–C4 figure.
Recyclability	Fully recyclable
Recycled content As defined in clause 7.8 of BS EN ISO 14021	42 %
