Equinox Conservatory Roof - Tiled conservatory roof system

Verified by manufacturer 1 month ago

Composite slate tiles

Eurocell plc Variant:

Tiled warm roof for conservatories

Jump to:
+44 (0)1773 842100 Website

Application

Suitable for all conservatory roof types, including:

  • Edwardian
  • Gable-ended
  • Lean-to
  • P-shaped
  • Victorian
  • Flat roofs
  • Extensions
  • Porches

Description

Tiled conservatory roof system, including flush-fitting rafters, box gutters and a variable ring beam. It has an internal plastered finish and a plasterboard or tongue-and-groove timber ceiling in a wide choice of colours. Often used as a replacement for aging glass or polycarbonate roofs.


Features and benefits:

  • Tiles are lightweight
  • Four different tile options, including Envirotile
  • Fully insulated
  • Options to include rooflight or fully glazed panels
  • Variable pitches between 10–35º offer flexibility (dependent on tile type chosen)
  • Greater structural strength than traditional conservatory roofs
  • Easy and quick installation; nuts and bolts are already in position
  • Multi-layered roof design minimizes moisture build-up in the roof space, restricting condensation issues, and air gaps within the roof dissipate moisture quickly
  • Right-angled rafters and variable hips
  • Becomes watertight on the same day and can be left overnight
  • Good thermal efficiency with U-values as low as 0.15 W/m²K
  • Noise levels can be significantly reduced
  • Reduced ring-beam overhang solves problems with conservatories on boundary lines
  • Internal solid roof structure system enhances structural support and ensures no loadbearing issues or loss of strength
  • Gable end component allows improved finishing for gutters on gable end design
  • All sealants and fixings supplied
  • Compliant with Building Regulations Part L
  • Ten-year guarantee

General information

Shape

Rectangle

Other

Length

Bespoke

Width

Bespoke

Height

Bespoke

Warranty description

Ten year

Uniclass

Pr_20_65_34_34 Glazed enclosuresPrimary

CAWS

B12/120 Conservatory

B12/5 Conservatory

Product range

Conservatories

Specification data - Glazed enclosures

Style

Equinox.

Roof

-

Frame

-

Material

Limestone and polypropylene.

Guidance for specification option:

Made from a recyclable mix of limestone and polypropylene.

Finish

Plastered.

Colour

Not required.

Guidance for specification option:

If a different type has been chosen.

Brick red.

Chestnut.

Pewter grey.

Plum.

Stone black.

Hardware

Flush-fitting rafters.

Box gutters.

Ring beam.

Accessories

None.

Flush-fitting rafters.

Box gutters and a variable ring beam.

Roof windows

Electric pivot.

Manual pivot.

Guttering

Black.

Brown.

Clay brown.

White.

Fascia

Anthracite grey.

Black ash.

Chartwell green.

Cream.

Golden oak.

Show more

Ceiling

Plasterboard.

Tongue and groove.

U-value

0.15 W/m²K.

Guidance for specification option:

U-values as low as 0.15 W/m²K.

PitchAngle

10–35º.

Guidance for specification option:

(dependent on tile type chosen).

Literature

Equinox Tiled Roof System Guide

Equinox Tiled Roof System Guide

Equinox Tiled Roof Product Chart

Equinox Tiled Roof Product Chart

Equinox Tiled Roof 10 Year Product Guarantee Certificate

Equinox Tiled Roof 10 Year Product Guarantee Certificate

Equinox Roof Product Chart

Equinox Roof Product Chart

Equinox Tiled Roof Consumer Brochure

Equinox Tiled Roof Consumer Brochure
