INTEGRA 4000 Series - UL Fire Rated Riser Doors

Verified by manufacturer 3 months ago

INTEGRA 4000 Series UL FR Riser Doors - Single Door

Access 360 Variant:
Third party certifications:
  • ISO 9001 Quality Management

    Certificate type

A UL Certified, two hour fire-rated riser door used to provide permanent, safe and discreet access to electrical and other services located within the riser shaft of the building.

Jump to:
+44 (0)1827 718222 Website

Application

  • For commercial, residential and public buildings.
  • Provides access into jointless plaster, plasterboard wall and masonry walls where access to mechanical and electrical services is required.
  • Suitable for riser, duct and pod access applications for jointless plasterboard/ plaster and masonry walls.

Description

Third party UL Certified fire-rated riser doors for commercial and residential buildings where concealed maintenance-free access is required to mechanical or electrical services within the riser shaft, without compromising on building aesthetics or finish.

Designed and manufactured the UK to exact specifications, the riser doors fit seamlessly into masonry walls, shaft walls and drywall partitions.


Features and benefits:

  • Tested in accordance with UL 10B - Fire Tests of Door Assemblies Standard for Safety.
  • Virtually invisible, for a clean, discreet design.
  • Seamless aesthetic finish.
  • Fast and simple to install, lockable.
  • Etch primed for decorating on site, to match adjacent finishes
  • Single Door (SD) and double door (DD) configurations.
  • High performance range, for vertical use with frame and lock options.
  • Fully recyclable at end of life.

General information

Color

White

Guidance for specification option:

RAL 9010.

Finish

Matt

Guidance for specification option:

Powder coated.

Powder-coated

Material

Steel

Guidance for specification option:

Electro-galvanized mild steel.

Shape

Rectangle

Width

450 mm

550 mm

600 mm

1080 mm

1200 mm

Show more

Height

450 mm

600 mm

900 mm

1200 mm

1500 mm

Show more

Warranty description

Five year

Uniclass

Pr_30_59_24_52 Carbon steel doorsetsPrimary

CAWS

K10/125 Metal stud partition system

K10/115 Metal stud partition system

K10/145 Wall lining system (metal studs)

K10/155 Wall lining system (metal studs)

K10/165 Wall lining system (metal framing)

K10/215 Suspended ceiling system

K10/220 Proprietary suspended ceiling system

K10/430 Access panels

K10/15 Lining on timber

K10/30 Metal stud

L20/55 Doorsets

K10/35 Wall lining system (metal framing)

K10/50 Suspended ceiling system on metal framing

L20/480 Doorsets

L20/630 Hatches

K10/25 Ceiling lining on timber

Specification data - Carbon steel doorsets

Configuration

Single door (SD).

Doorset size

450 x 450 mm.

550 x 900 mm.

550 x 1200 mm.

600 x 1500 mm.

Performance

-

Fire resistance

-

Integrity

1 hour fire rated (1FR).

2 hour fire rated (2FR).

UL certified (UFR).

Guidance for specification option:

UL certification available.

Reaction to fire

To BS EN 12207:2016 or BS EN 1026:2016.

Acoustic performance

35 dB.

Frame

-

Material

Electro-galvanised mild steel.

Perimeter seals or inserts

All-in-one acoustic, intumescent and smoke seal.

Finish

-

Coating

Powder-coated.

Texture

Matt.

Special order.

Guidance for specification option:

Other textures available, consult manufacturer and insert requirements.

Colour

RAL 9010, white.

Guidance for specification option:

Standard and can be overpainted on site to match surrounding area.

Special order.

Guidance for specification option:

Other RAL paint colours available, consult manufacturer and insert requirements.

Door leaf

-

Thickness

1.2 mm.

Panel details

Rockwool.

Guidance for specification option:

Fire rated doors only, with 12.5mm FireLine board door leaf backing.

Material

Electro-galvanised mild steel.

Guidance for specification option:

1.2 mm Zintec steel door leaf.

Accessories

Not required.

Ironmongery.

Guidance for specification option:

Different ironmongery options available, consult manufacturer and insert requirements.

Left hand opening.

Right hand opening.

Door closers.

FrameDepth

59 mm.

Guidance for specification option:

90 mm deep rebated frame with smoke seals.

Fixing

Wall mounted.

Manufacturer guidance

Frame.

Operation

Full length concealed piano hinge.

Manufacturer guidance

Panel.

Colour

RAL 9010, white, powder-coated matt.

Guidance for specification option:

Standard and can be overpainted on site to match surrounding area.

Special order.

Guidance for specification option:

Other RAL paint colours available, consult manufacturer and insert requirements.

Manufacturer guidance

Panel.

Latch or lock type

3 point budget lock (3PL).

Guidance for specification option:

  • T bar key: used to unlatch and pull door leaf open.
  • Locking assembly: engages top, bottom and lock sides.
  • White plastic collar and plug as standard, with optional stainless steel collar.

High security lock (3HS).

Guidance for specification option:

  • T bar key: used to unlatch and pull door leaf open.
  • Secondary locking.
  • Locking assembly: engages top, bottom and lock sides.
  • White plastic collar and plug as standard, with optional stainless steel collar.

Profile

Picture frame (PF).

Guidance for specification option:

  • With visible 25 mm architrave for installation into finished walls.
  • Ideal for retro fitting and finished areas.

Beaded frame (BF).

Guidance for specification option:

  • For installation into unfinished walls.
  • Tape and jointed or plaster skimmed over to give a frameless finish.

Manufacturer guidance

Frame.

Third-party certification

UL label.

Guidance for specification option:

Approved to UL 10B for up to 2 hours fire resistance in Single Door (SD) and Double Door (DD) configurations and carries the UL label » (USA and CANADA).

Sustainability data

Contains Red List materials

No

Country of material origin

Europe

Country of product manufacture

United Kingdom

Guidance for specification option:

Britain.

Material

Steel

Guidance for specification option:

Electro-galvanized mild steel.

Recyclability

98%

Recycled content

As defined in clause 7.8 of BS EN ISO 14021

25 %

Third party certifications

ISO 9001 Quality Management

ISO 9001 Quality Management

Quality Management Systems
