Invicta Block Paving

Name: Invicta Block Paving
Brand: Brett Landscaping
SKU: 7834JjGEPMW2f8d4STYDLT

Verified by manufacturer 5 months ago

80 mm single size pack, 200 x 100 mm

Brett Landscaping

Third party certifications:

EPD
Certificate type
ISO 9001 Quality Management
Certificate type
ISO 45001 Health and Safety Management
Certificate type

Invicta uses a unique combination of natural aggregates on the top surface to create a hard wearing, long lasting paving solution whilst offering a stunning vibrant finish with a hint of sparkle.

Jump to:

+44 (0)345 60 80 570 Website

Application

Domestic and commercial use; hardstanding for vehicular and pedestrian pavements including footpaths, cycle tracks, driveways, adoptable highways, commercial pavements, roof top and balcony applications.

Description

Invicta uses a unique combination of natural aggregates on the top surface to create a hard wearing, long lasting paving solution whilst offering a stunning vibrant finish with a hint of sparkle. Invicta is available in four complementary colours and both traditional and contemporary plan sizes, making this a versatile product suitable for most projects.

Features and benefits:

For domestic and commercial use.
Hardstanding for vehicular and pedestrian pavements.

General information

Color	Grey Silver Yellow
Finish	Textured
Material	Concrete Guidance for specification option: Precast (Agg-Tech semi-dry-pressed and vibrated).
Shape	Square Rectangle
Length	200 mm 300 mm
Width	100 mm 200 mm
Height	80 mm

Uniclass	Pr_25_93_60_17 Concrete paving blocksPrimary
CAWS	Q24/10 Conventional concrete block paving Q24/110 Conventional concrete block paving

Specification data - Concrete paving blocks

Standard	To BS EN 1338:2003. Guidance for specification option: Design standard: To BS 7533-1:2001; To BS 7533-2:2001. Installation standard: To BS 7533-3:2005 + A1:2009.
Physical properties	-
Colour	Pearl. Onyx. Citrine. Moonstone.
Finish	Textured.
Profile	-
Paver type	Regular plan form.
Arrises	Chamfered.
Dimensions and associated tolerances	-
Nominal sizes	200 x 100 x 80 mm. Guidance for specification option: Unit weight: 3.86 kg.
Arrises	Chamfered (textured finish).
Weathering resistance	Class 3.
Abrasion resistance	Class 3. Guidance for specification option: ≤23 mm, determined by Wide Wheel Abrasion test.
Slip resistance	Unpolished Slip Resistance Value (USRV): ≥55; Potential for slip: Low. Guidance for specification option: Unpolished slip resistance value.

Reaction to fire	Class A1. Guidance for specification option: When used for internal flooring.
ThermalConductivity	1.2 W/m·K.
Strength	Characteristic tensile splitting strength ≥3.6 MPa; Failing load ≥250 N/mm.
Tolerances on plan dimension and thickness nominal	Thickness: ±3 mm; Plan size: ±2 mm.
