Junior 120 B (Sliding Door Hardware)
Verified by manufacturer 4 months ago
Junior 120 B (25908)
Junior 120 B (25908)
EPD
Certificate type
Sliding hardware with top fixed suspension, for use with single wooden doors with a panel weight up to 120 kg.
Application
Suitable for use in low headroom applications.
Description
Sliding hardware with top fixed suspension, for use with single wooden doors with a panel weight up to 120 kg.
Features and benefits:
- Suitable for use in low headroom applications.
- Lateral fixing of trolleys for sliding doors running in the ceiling.
- Light, silent action.
- Vertically adjustable (±3 mm).
- Can be provided in a wall pocket configuration.
Components:
Quantities of each component will vary dependent on variant specified (consult manufacturer for details).
- Two-wheeled trolley M12, with plastic wheels.
- Top fixed suspension with plate and hanger bolt M12.
- Plastic cover cap for top fixed suspension, anthracite grey RAL 7016.
- Track stop with adjustable retaining force (25908) and with two track stops (26042), if the sliding door needs to stop at both ends.
- Screw-on rubber door stop.
- Rattle proof guide for screw mounting to floor with groove width 10 mm, black plastic.
- Suspension assembly locking wrench.
- For two-panel sliding doors.
- Order two sets for single doors.
- Consult manufacturer for further details.
General information
Color | Grey |
Finish | Anodized |
Material | Aluminium |
Shape | Rectangle |
Warranty description | Two year |
Uniclass | |
CAWS | P21/10 Door track and running gear P21/350 Door track and running gear |
Specification data - Door track and running gear
Standard | To EN 1527. |
Third-party certification | TÜV Rheinland LGA Products GmbH, Nürnberg, Germany. |
Classification grades (minimum) | |
Durability | 6. |
Door mass | 3. |
Initial friction | 1. |
Form | Aluminium, plain anodized, pre-drilled, top hung running track.Guidance for specification option:
Wall pocket.Guidance for specification option:
|
Running track | 2500 mm. 3000 mm. 4000 mm. 6000 mm. Cut to size. Guidance for specification option: Insert requirements. |
Closing mechanism | Not required. SoftMove 120. |
Accessories/ Other requirements | Not required. Bottom door stop. Guidance for specification option: Available with dull chromium or stainless steel finish; insert requirement. Cover cap for running track. Guidance for specification option: Dull chromium finish. Guide profile. Guidance for specification option: Black, plastic. Groove mounted. 1300 mm length. Hawa Adapto 120. Guidance for specification option:
Manufacturer guidanceSpares are also available, consult manufacturer for details. |
Components | One track stop. |
Sustainability data
Contains Red List materials | No |
Country of material origin | Switzerland |
Country of product manufacture | Switzerland |
Recyclability | Yes |
Third party certifications
Third party certifications
EPD
Hawa EPD Sliding door gear EN
Literature
CAT_EN_Hawa_Junior_120_B
