MOY PE AVCL - Polyethylene Air & Vapour Control Layer

Verified by manufacturer 1 month ago

MOY Third party certifications:
  • BBA Agrément Certificate

    BBA Agrément Certificate

    Certificate type

Unsupported, age resistant and UV-stabilized vapour barrier made from sheet polyethylene.

Jump to:
+44 (0)1245 707 449 Website

Application

Can be applied on most common substrates - the substrates should be smooth, dry and strong enough to support foot traffic. On rough surfaces a levelling layer must be installed beneath the AVCL.

Description

MOY PE (Polyethylene) air and vapour control layer is an unsupported, age resistant and UV stabilized vapour barrier made from sheet polyethylene.


The AVCL should be installed on the inner warm side of the construction, beneath the thermal insulation and in buildings with low/normal humidity levels. Continuous sealing of the joints and at abutments or penetrations, prevents air leakage and water vapour transmission into the roof construction.


Features and benefits:

  • Ease and speed of installation.
  • Flexible at low temperatures.
  • CE marked.

General information

Color

Yellow

Material

Polyethylene

Shape

Other

Length

50000 mm

Width

4000 mm

Warranty description

-

Manufacturer guidance

For the duration of the MOY Warranty.

Uniclass

Pr_25_57_65_60 Plastics sheetsPrimary

CAWS

J42/395 Air and vapour control layer

P10/60 Air and vapour control layer

P10/310 Air and vapour control layer

J42/110 Warm deck roof covering

J42/10 Warm deck roof covering

Specification data - Plastics sheets

Material

Polyethylene (PE).

Purpose

Air and vapour control layer.

Standard

To EN 13984.

Performance characteristics

-

Tear resistance

≥35 N (longitudinal); ≥35 N (transverse).

Manufacturer guidance

(Nail shank).

Water vapour resistance (minimum)

>50 m.

Guidance for specification option:

>2.72 x 1011 (±30%) m²sPa/kg.

Manufacturer guidance

Sd-Value.

Fire performance

Class F.

UV stabilization

Not suitable for permanent exposure to UV.

Guidance for specification option:

Protect from direct sunlight during storage.

Third-party certification

CE certified.

Form

Sheet polyethylene.

Physical properties

-

Colour

Yellow.

Weight (minimum)

25.76 kg.

Dimensions

-

Width (minimum)

4 m.

Roll length (minimum)

50 m.

Sustainability data

Contains Red List materials

No

Country of material origin

Norway

Country of product manufacture

Norway

Third party certifications

BBA Agrément Certificate

BBA Agrément Certificate

Protan SE BBA 98/3459
