Q40 - Flush Faced WC Cubicle System
Verified by manufacturer 9 months ago
Q-40
Q-40
A modern design washroom cubicle system.
Application
Suitable for modern office blocks and nightclubs where gender neutral/ unisex washrooms optimize space and provide maximum privacy.
Description
A modern designed washroom cubicle system which is useful to create a stylish look while maintaining maximum privacy, available in Q-40 and Q-40 Tall units.
Features and benefits:
- Has minimalistic fittings to help enhance design.
- Sprung hinges designed to self close.
- Discreet 25 mm high leg or floor fixing pad available.
- Screen printed Male/ Female pictograms at additional cost.
- Doors/ pilasters 40 mm thick, rebated on clashing edge.
- Outward opening doors retain the sleek flush finish.
- Partitions 19 mm thick.
- Headrail required for 2000 mm version in various styles.
- Real wood veneer finish available at additional cost.
- Q-40 Tall: Designed with a 25 mm clearance top and bottom.
General information
Color | Other Guidance for specification option: Realistic wood grain effects or plain colours. |
Finish | Laminated |
Material | MFC |
Shape | Rectangle Square Other |
Length | Bespoke |
Width | Bespoke |
Height | Bespoke |
Warranty description | One year |
Uniclass | |
CAWS | K32/120 Panel cubicles K32/10 Panel cubicles K32/112 Fully framed panel cubicles |
Specification data - Panel cubicle systems
Panels | Flush faced panel. |
Pilasters | 40 mm.Guidance for specification option: Rebated on clashing edge. |
Doors | Outward opening. |
System accessories | Clothes hooks.Toilet roll holders. |
Ironmongery | Stainless steel. |
Thickness | 19 mm. |
Nominal height | 2000 mm. |
Sustainability data
Contains Red List materials | No |
Country of product manufacture | United Kingdom |
BIM objects
NBS BIM Object Standard
This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.
Find out more about the NBS BIM Object Standard.
| Platform | Compatible | Version |
|---|---|---|
 IFC | - | 1 |
 Revit | - | 1 |
