Quartzglide 3 - Single Glazed Pocket Sliding Door - Pocket door, sliding, glass, acoustic
Verified by manufacturer 12 days ago
ISO 9001 Quality Management
Certificate type
ISO 45001 Health and Safety Management
Certificate type
Single glazed frameless glass door offering up to 31 dB acoustic isolation.
Application
Open-plan commercial offices and workplace environments.
Description
Where acoustic privacy in conjunction with frameless glass is required Quartzglide 3 is the solution.
Features and benefits:
- Combined with the Apton Quartz double glazed system, Quartzglide 3 provides the highest level of acoustic performance with an unmatched elegance.
General information
Color | Clear Silver Other |
Finish | Glazed Laminated Powder-coated Satin Anodized |
Material | Glass Aluminium |
Shape | Rectangle |
Length | Bespoke |
Width | Bespoke |
Height | Bespoke |
Warranty description | Five year |
Uniclass | |
CAWS | L20/460 Frameless glass doors L20/520 Sliding doors L20/525 Sliding pocket doors L20/65 Sliding pocket doors |
Specification data - Sliding door and partition sets
Performance | Sound-resistant. |
Arrangement | As schedule.As drawing.Guidance for specification option: Insert drawing reference number. |
Track system | Aluminium, top-hung. |
Door leaves | |
Construction | 100 x 43 mm aluminium profiles. |
Finish and colour | Powder coated.Guidance for specification option: Insert requirements; contact manufacturer for more details. Satin.Guidance for specification option: Anodized aluminium. Anodized.Guidance for specification option: Inquire with manufacturer for special anodized finish options. |
Operation | Manual. |
Hardware | Guidance for specification option: A wide range of hardware options are available. Insert requirements; consult with manufacturer for details. |
Standards | To BS EN ISO 140, BS EN ISO 717, BS5234, BS6180 and BS6399. Guidance for specification option: British standards:
|
Height | Guidance for specification option: Available height up to 3000 mm; insert requirements or drawing reference number. |
Glass thickness | 10–12.8 mm. |
AcousticRating | Up to 31 dB (Rw). |
Glass type | Toughened - laminated. Manufacturer guidanceAvailable 'Switch Glass' option; contact manufacturer. |
Manifestation | Not required. Required. Guidance for specification option: Insert requirements; contact manufacturer for details on optional manifestations and graphics. |
Sustainability data
Contains Red List materials | No |
Country of material origin | United Kingdom |
Country of product manufacture | United Kingdom |
Material | Glass Aluminium |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 90 % |
BIM objects
| Platform | Compatible | Version |
|---|---|---|
 Revit | - | 1 |
Third party certifications
ISO 9001 Quality Management
BS EN ISO 9001:2015
ISO 45001 Health and Safety Management
ISO 45001:2018 Occupational Health and Safety Management Systems
Literature
Sliding Door Quartzglide 3
Case studies
Amazon Offices by Apton Partitioning
