Rainline Magestic Galvanised Steel Rainwater System

Verified by manufacturer 4 months ago

Lindab Ltd Third party certifications:
  • EPD

    EPD

    Certificate type

Rainline steel gutter and pipe system with an unpainted, galvanised surface finish.

Jump to:
+44 (0)1604 788350 Website

Application

For use in varying applications, including:

  • Large or small roof areas.
  • Classic or contemporary buildings.
  • Domestic or commercial use.



When selecting gutter and pipe sizes for a rainwater system, the size of the roof and the downpipes position should be considered. This helps ensure that typical rainfall will not cause system overflow. Consult manufacturer for further details.

Description

Rainline steel gutter and pipe system with an unpainted, galvanised surface finish.



Features and benefits:

  • Provides an attractive, organic aesthetic.
  • Will weather to a dark grey, metallic appearance within 3–5 years after installation.
  • Low carbon footprint and low overall environmental impact.
  • Durable and flexible.
  • Manufactured from 30% recycled steel, which is more lightweight than cast iron, easier to handle than aluminium and offers minimal thermal movement compared to plastic.
  • Minimal maintenance required.
  • Highly resistant to vandal attack; further reinforcement can be added if required.
  • UV-stable.
  • Gutters available in four sizes, pipes available in four sizes.
  • Quick and easy to install with snap-mounting outlets, self-sealing stop ends and click-lock gutter joints.
  • Supplied with a ten-year warranty.
  • Manufactured in accordance with BS EN 12056-3: 2000.

General information

Color

Grey

Silver

Finish

Galvanized

Material

Steel

Shape

Circle

Rectangle

Length

3000 mm

2000 mm

Width

100 mm

125 mm

150 mm

190 mm

Height

50 mm

63 mm

75 mm

95 mm

Warranty description

Ten year

Uniclass

Ss_50_30_02_28 External gravity rainwater drainage systemsPrimary

CAWS

R10/110 Gravity rainwater drainage system

Specification data - External gravity rainwater drainage systems

System performance

To BS EN 12056-3: 2000.

Eaves gutters

-

Gutters

-

Gutter types

Rainline Magestic Galvanized Gutter Half-round - 100 mm.

Rainline Magestic Galvanized Gutter Half-round - 125 mm.

Rainline Magestic Galvanized Gutter Half-round - 150 mm.

Rainline Magestic Galvanized Gutter Half-round - 190 mm.

Rainline Magestic Galvanized Gutter Rectangular - 140 mm.

Jointing

RSK gutter joint with rubber seal.

Guidance for specification option:

For Half round.

RTSK rectangular gutter joint with rubber seal.

Guidance for specification option:

For Rectangular - 140 mm.

External rainwater pipework

-

Rainwater downpipes

-

Downpipe types

Rainline Magestic Galvanized Rainwater Downpipe, 75 mm.

Rainline Magestic Galvanized Rainwater Downpipe, 87 mm.

Rainline Magestic Galvanized Rainwater Downpipe, 100 mm.

Supports

-

Brackets and clips

SST spike for pipe bracket, 125 mm.

SST spike for pipe bracket, 175 mm.

SST spike for pipe bracket, 250 mm.

SST spike for pipe bracket, 300 mm.

SSVU universal pipe bracket.

System accessories

-

Manufacturer guidance

Selection of brackets, sliding pipes, diverters, hoppers, shoes, connectors, branches, access pipes, offsets and intermediate pipes etc are available dependent on size. Consult manufacturer for details.

Colour/ Finish

Painted, RAL 7016 gloss finish.

Unpainted galvanized finish.

Sustainability data

Contains Red List materials

No

Country of material origin

Sweden

Country of product manufacture

Sweden

Material

Steel

Manufacturing plant location

Recyclability

Fully recycleable

Recycled content

As defined in clause 7.8 of BS EN ISO 14021

30 %

Expected Life

50 year

Third party certifications

Third party certifications

EPD

Lindab Rainline EPD
