Rockfon Contour® - Frameless Acoustic Baffles

Verified by manufacturer 16 days ago

Rectangle - 1200 x 300 x 50 mm

Rockfon

Product certifications:

Cradle to Cradle Certified
Certificate type
EPD
Certificate type

Economic and aesthetically pleasing, frameless vertical acoustic baffles.

Jump to:

+44 (0)208 2227457 Website

Application

Suited for enhancing acoustics in thermal mass areas or for use where frequent and unhindered access to services is required, including:

Education;
Retail;
Healthcare;
Industry;
Offices;
Leisure.

To be installed using the Rockfon® System Contour Baffle™ installation system. Not suitable for use in swimming pools or outdoors – consult manufacturer for details.

Description

Stone wool frameless acoustic ceiling baffles with a straight edge or wave shapes.

Features and benefits:

Class A sound absorption and Class A1 fire safety.
Aesthetically pleasing and attractive to the visible side, with a smooth, matt fleece.
Can be used alone, or to enhance the sound absorption of an existing ceiling.
Quick and easy to install; anchor points are integrated during production.
Easy to clean with a vacuum cleaner.
Hygienic stone wool provides no sustenance to micro-organisms.
Includes bevelled and painted edges.
Can be fully recycled.
Other configurations may be available - consult manufacturer for details.
Rockfon acoustic solutions are Cradle to Cradle Certified® Bronze.

Humidity and sag resistance:

Dimensionally stable, even at humidity levels of up to 100% RH.

Cleaning:

The surface can be vacuum cleaned with a soft brush attachment.

General information

Color	White
Finish	Smooth Matt
Material	Stone wool
Shape	Rectangle Other Guidance for specification option: Wave.
Length	1200 mm 1800 mm
Width	300 mm 600 mm 400 mm 450 mm 150 mm
Height	50 mm

Uniclass	Ss_30_25_22_01 Acoustic baffle suspended ceiling systemsPrimary Pr_35_93_13_53 Mineral fibre infill units Pr_35_93_13_80 Sound attenuator infill units
CAWS	K40/115 Unit/ modular suspended ceiling system K40/10 Unit/ modular suspended ceilings K40/265 Infill units

Product range	Baffles

Specification data - Acoustic baffle suspended ceiling systems

System performance	Acoustic performance: Class A; Reaction to fire: Class A1.
Ceiling units	Baffles.

Edges	A.
Colour	Super white.
Size (l x w)	1200 x 300 mm.
Thickness	50 mm.
Finish	Smooth, matt fleece.
Light reflectance	79%.
Weight	2.2 kg.
Certification	Cradle to Cradle Certified® Silver.
Shape	Rectangle.

Sustainability data

Contains Red List materials	No
Country of product manufacture	Poland
Material	Stone wool
A1-A3 (production stage)	Embodied carbon as defined in BS EN 15804
Normalised unit	6.1 kg CO₂ eq/kg
Declared unit	6.08 kg CO₂ eq/kg Certified
Recyclability	100%
Recycled content As defined in clause 7.8 of BS EN ISO 14021	38 %
