Application

Suitable for use in car showrooms, retail stores, conservatories, atriums, reception halls and conference zones.

IMPORTANT: All specification information must be checked against the individual site requirements. Flowcrete advises that specifications are confirmed with their technical experts.

Description

A decorative commercial flooring system that contains marble encapsulated in clear resin to produce a slip-resistant floor finish. The system can be laid in bespoke patterns and styles.


Features and benefits:

  • Decorative.
  • Noise reducing.
  • Aesthetic.
  • Hard wearing.
  • Rapid installation.
  • Versatile.

General information

Color

Finish

Gloss

Material

Marble

Resin

Warranty description

Five year

Uniclass

Ss_30_42_54_75 Resin flooring systemsPrimary

CAWS

M12/10 Resin flooring

M12/110 Resin flooring

Specification data - Resin flooring systems

Primer

Peran STC.

Abrasion resistance

Class AR2 - Medium duty industrial.

Bond strength

Greater than cohesive strength of 25 N/mm² concrete (>1.5 MPa).

Colour options

Black.

Green.

Beige.

Dark grey.

Pink.

Show more

CompressiveStrength

50 N/mm².

Cure time

Light traffic: 24 hours, Full traffic: 2 days, Full chemical cure: 7 days.

Flexural strength

10 N/mm².

Impact resistance

To ISO 6272, 1 kg > 1.8 m, 2 kg > 1.5 m.

Samples required

Guidance for specification option:

As required.

Slip resistance

Dry >40 low slip potential.

Subgrade improvement layer

If required: heavy duty screed.

Suitable substrates

Concrete or screed with a minimum compressive strength of 25 N/mm².

Binder

Peran RC Resin.

Chippings

Marble.

Thickness range

8–12 mm.

Toxicity

Taint free to sensitive foodstuffs.

Uses

Car showrooms, retail stores, conservatories, atriums, reception halls, conference zones.

Water permeability

Permeable.

BIM objects

BOS

NBS BIM Object Standard

This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.

Find out more about the NBS BIM Object Standard.

Platform Compatible Version
Revit
-

3

IFC
-

2
