Sentry® Residential Railings - Steel railings

Verified by manufacturer 4 months ago

Jacksons Fencing Third party certifications:
  • ISO 9001 Quality Management

    Certificate type

Metal railings which are a smaller, more elegant alternative to Sentry vertical bar fencing, suitable for residential properties and light commercial applications.

Jump to:
0800 408 4757 Website

Application

Suitable for use in town or housing applications.

Description

Contemporary metal railings with narrow pales for an elegant look, suitable for residential properties as a simple demarcation solution.


Features and benefits:

  • Vandal-proof connectors.
  • Contemporary demarcation fencing.
  • 25-year guarantee.
  • Lightweight, tubular construction.


Sentry Residential Railings correspond(s) to the generic component/material "steel" in the BRE Global Guide online generic specification(s) "Galvanised steel railings" which achieve(s) a summary rating of B within commercial, domestic, residential, health, industrial, education.

General information

Color

Black

Green

Other

Finish

Powder-coated

Galvanized

Material

Steel

Width

3000 mm

Height

1250 mm

1000 mm

Manufacturer guidance

Panels.

Warranty description

25 year

Uniclass

Ss_25_15_60_55 Metal post and panel barrier systemsPrimary

CAWS

Q40/30 Proprietary fencing

Q40/340 Steel vertical bar fencing

Q40/430 Proprietary fencing

Product range

Metal Railings

Specification data - Metal post and panel barrier systems

Preparatory work

To system manufacturer’s recommendations.

Posts

60 x 60 mm with anti-tamper fixings with internal connector and no visible bolts.

Post foundations

Over length set in concrete.

Guidance for specification option:

As standard.

Base plated to bolt down onto concrete.

Cranked to suit wall mounting.

Rails

50 x 25 mm rectangular hollow section (RHS).

Panels

19 mm round pales at 100 mm spacing, 1000 mm high.

19 mm round pales at 100 mm spacing, 1250 mm high.

Manufacturer guidance

Colour/ finish specified separately below.

Flat fence topping as standard.

System accessories

None.

Matching gates, single leaf.

Matching gates, dle leaf.

Manufacturer guidance

Specify gates in detail separately.

Finish/ Colour

Galvanized and powder coated, black RAL 9005.

Guidance for specification option:

Standard.

Galvanized and powder coated, green RAL 6005.

Guidance for specification option:

Standard.

Galvanized and powder coated, BS.

Guidance for specification option:

Special order, insert requirements.

Galvanized and powder coated, RAL.

Guidance for specification option:

Special order, insert requirements.

Marine coated.

Guidance for specification option:

For applications near sea water.

Sustainability data

Contains Red List materials

No

Country of product manufacture

United Kingdom

Third party certifications

ISO 9001 Quality Management

ISO 9001 Quality Management

ISO 9001:2015 Quality Management System
