Sound Insulating Doorset - Acoustic doors

Verified by manufacturer 19 days ago

Sound Insulating Door, 42 dB (maximum)

Shadbolt International Variant:

Sound insulating doorset.

Jump to:
+44 (0)1376 333376 Website

Application

Suitable for top-level offices, auditoriums and plant rooms.

Description

Acoustic doors are specialist assemblies offering a higher level of sound insulation, 44 dB SRI Rw (maximum) where required, e.g. in top-level offices, auditoriums and plant rooms. Certain doors in this range can also provide 30 or 60 minutes fire resistance, and the same high quality of appearance and performance as all Shadbolt doors.


Features and benefits:

  • Acoustic doors offering higher level of sound insulation.
  • Certain doors provide 30 or 60 minutes fire resistance.



General information

Finish

Matt

Guidance for specification option:

Door leaf face and frames.

Gloss

Guidance for specification option:

Frame.

Satin

Guidance for specification option:

Frame.

Stained

Guidance for specification option:

Frame.

Material

Laminate

Guidance for specification option:

Plastic laminate.

Wood

Guidance for specification option:

Wood veneer, hardwood, and softwood.

Glass

Medium density fibreboard (MDF)

Shape

Rectangle

Length

Bespoke

Manufacturer guidance

Maximum.

Width

Bespoke

Manufacturer guidance

Maximum.

Height

Bespoke

Warranty description

One year

Uniclass

Pr_30_59_24_97 Wood doorsetsPrimary

CAWS

L20/410 Wood doorsets

L20/55 Doorsets

Product range

Acoustic Doors and Doorsets

Specification data - Wood doorsets

Third-party certification

QA Certificate.

Performance

-

Fire resistance

-

Integrity

Not required.

To BS 476-22, 30 minutes.

To BS 476-22, 60 minutes.

Acoustic performance

42 dB SRI Rw (maximum).

Frame

-

Material

Hardwood.

MDF.

Softwood.

Manufacturer guidance

Manufacturer's choice to comply with performance and appearance required.

Finish

Semi-matt lacquer.

High gloss clear polyester.

Enamel satin lacquer.

Stain.

Manufacturer guidance

To complement veneered doors consult with manufacturer for details.


Door leaf

-

Thickness

59 mm.

Facings

Plastic laminate, colour.

Guidance for specification option:

Alternative facings.

Insert requirements.

Wood veneer, species.

Guidance for specification option:

Insert requirements.

Manufacturer guidance

Consult manufacturer available facings, details, and product references.

Species

Guidance for specification option:

Consult manufacturer's available wood veneer species.

Lippings

Lip four edges concealed.

Lip four edges exposed.

Manufacturer guidance

7 mm (minimum) thickness matching hardwood, applied using radio-frequency glue without tongue to all four edges.

Finish

Semi-matt lacquer.

Guidance for specification option:

For wood veneer facings.

Two coats of high-solid acid-catalysed semi-matt (20% gloss).

Semi-matt polyurethane lacquer.

Guidance for specification option:

For wood veneer facings.

Two coats of high-solid acid-catalysed semi-matt (20% gloss).

Semi-matt UV cured lacquer.

Guidance for specification option:

For wood veneer facings.

Two coats of high-solid acid-catalysed semi-matt (20% gloss).

Coloured plastic laminate.

Guidance for specification option:

For plastic laminate finish.

Consult with manufacturer for exact details and product references.

Manufacturer guidance

Finish as delivered.



Hardware

As schedule.

Architraves

-

Material

Hardwood.

MDF.

Softwood.

Manufacturer guidance

Manufacturer's choice to comply with performance and appearance required.

Finish

-

Manufacturer guidance

Consult manufacturer for exact details.

Glazed aperture

Not required.

Clear insulating.

Guidance for specification option:

Insert requirements

Thickness ___ mm, style ___.

As drawing.

Smoke seals

Not required.

Smoke stop required.

Sustainability data

Contains Red List materials

No

Country of material origin

Europe

Country of product manufacture

United Kingdom

Embodied carbon

A1-A3 (production stage) as defined in BS EN 15804

0.72 kg CO₂ eq/m³

Self declared

Literature

Acoustic doors and doorsets

Acoustic doors and doorsets
