Trosifol® Natural UV - UV Control laminated glass interlayer
Verified by manufacturer 1 month ago
Polyvinyl Butyral (PVB) interlayer
Application
- Greenhouses/botanical gardens
- Hospitals
- Children’s day care centers
- Schools and universities
- Zoo
- Flora
- Fauna
Description
Polyvinyl Butyral (PVB) interlayer for use in laminated safety glass.
High adhesion: Specially designed for laminated safety glass, made with heat strengthened or tempered glass. It reduces the risk of edge delamination. Good post breakage and structural properties.
Allows regulated sunlight to enter the building ideal for botanical areas and office space to help promote essential vitamin D production and promote wellness of animals and marine life.
General information
Color | Clear |
Material | Polyvinyl butyral (PVB) |
Length | 200000 mm |
Width | 1000 mm 1600 mm 2250 mm 2600 mm 3210 mm |
Height | 0.76 mm |
Uniclass | |
CAWS | L40/530 Internal tape glazing L40/515 Fire-resistant channel glazing – plastics/ elastomeric channel L40/510 Fire-resistant channel glazing – solid section channel L40/505 Fire-resistant tape/ Strip glazing L40/490 Single-sided gasket glazing L40/470 Zipper gasket glazing L40/450 Single glazing into grooves – sealant capping L40/430 Single glazing into grooves – non-setting compound L40/410 Single glazing into grooves – extruded rubber/ PVC sections L40/90 Internal tape glazing L40/80 Fire-resistant channel glazing – plastics/ elastomeric channel L40/75 Fire-resistant channel glazing – solid section channel L40/65 Fire-resistant tape/ Strip glazing L40/50 Bead-fixed single glazing L40/40 Putty-fronted single glazing L40/350 Bead-fixed single glazing – curing compound and trim L40/330 Bead-fixed single glazing – capping L40/310 Bead-fixed single glazing – tape, sealant and trim L40/260 Bead-fixed single glazing – extruded gasket L40/250 Bead-fixed single glazing – tape and sealant L40/230 Bead-fixed single glazing – non-setting compound L40/210 Putty-fronted single glazing |
Specification data - Polyvinyl butyral (PVB) sheets
Thickness | 0.76 mm. |
Density | 1.07 g/cm³. |
ThermalConductivity | 0.21 W/mK. |
ThermalExpansionCoefficient | 1.7E-4 1/K. |
SpecificHeatCapacity | 1.9 J/g K. |
Tensile strength (to EN ISO 527) | >20 N/mm². |
Elongation at break | >250%. |
Colour | UltraClear. |
Light transmission | 89%. |
Sustainability data
Contains Red List materials | No |
Country of material origin | Germany |
Country of product manufacture | Germany |
Embodied carbonA1-A3 (production stage) as defined in BS EN 15804 | 3.34 kg CO₂ eq/m² Self declared |
Recyclability | 100% Recyclable |
