113 Series Wall Expansion Joint System
Verified by manufacturer 3 months ago
113-A09-025
113-A09-025
113 Series Recess Mount - Wall to corner or wall to wall.
Application
Recess mounted expansion joint for wall and ceiling systems.
Description
113 Series Recess Mount - Wall to corner or wall to wall.
Features and benefits:
- Minimal sightline.
- Dual durometer seal provides a secure fit and optimal flexibility.
- Designed for 5/8" (16 mm) plasterboard installations.
- Finish with plaster joint compound or wall covering.
- Easy to clean flush seals.
- Snap-fit design for easy on site assembly.
- Standard seal colours: black, beige, grey, off white and bright white. Custom colours available upon request.
General information
Shape | Rectangle |
Color | Black Beige Grey White Guidance for specification option: Off white and bright white. Manufacturer guidanceCustom colours available on request. |
Finish | Mill Guidance for specification option: Clear. |
Material | Aluminium Rubber Guidance for specification option: Synthetic. |
Warranty description | Five year Guidance for specification option: Standard limited warranty against material and manufacturing defects for a period of not less than five years when installed in accordance with manufacturer’s recommendations. |
Uniclass | |
CAWS | Q21/470 Expansion joints |
Specification data - Metal section movement joints
Joint width (nominal) | 25 mm. |
Edging | |
Material | Aluminium. |
Finish | Mill.Guidance for specification option: Clear. |
Colour | Natural. |
Insert | |
Material | Synthetic rubber. UL Greenguard Gold Certified Santoprene Rubber.Guidance for specification option: Santoprene seal. |
Colour | Black.Beige.Grey.Off white.Bright white.Other.Guidance for specification option: Custom colours available on request. |
Options | Not required. Fire blanket system. EPDM vapour barrier. |
Joint type | Wall to corner. |
Sightline | 25 mm. |
Sustainability data
Contains Red List materials | No |
Country of material origin | United States |
Country of product manufacture | United States |
Recyclability | 75% |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 71 % |
BIM objects
| Platform | Compatible | Version |
|---|---|---|
 Revit | - | 1 |
