Barbican Imperial® A1 (SR1) Fencing - Security rated fencing

Name: Barbican Imperial® A1 (SR1) Fencing - Security rated fencing
Brand: Jacksons Fencing
SKU: meNquh2yv9nkbhzXA9twCw

Verified by manufacturer 4 months ago

1800 mm-high panels

Third party certifications:

LPS 1175 security rated vertical bar fencing suitable for lighter commercial properties and residential developments.

Jump to:

Application

Residential properties; commercial premises; schools.

LPS 1175 security rated vertical bar fencing which combines strength and security with a non-intimidating aesthetic.

Features and benefits:

Anti-climb design.
LPS 1175 A1 (SR1)-approved.
Secured by Design preferred specification.
Fully welded pale-through-rail construction.
25-year guarantee.
Seamless, concealed rail to post fixing.
Matching single-leaf and double-leaf gates are available (specified separately).

Color	Black Green Other
Finish	Galvanized Powder-coated Manufacturer guidance [Finish, Hot-dip-galvanized, powder-coated]
Material	Steel
Width	3000 mm 2484 mm
Height	1000 mm 1250 mm 1500 mm 1800 mm 2000 mm 2500 mm 3000 mm Show more
Warranty description	25 year Guidance for specification option: Manufacturer's Service Life guarantee provides cover against defects such as design, manufacturing finish and fitness for purpose. Consult manufacturer for full details.

Uniclass	Ss_25_14_61_86 Steel vertical bar fencing systemsPrimary
CAWS	Q40/30 Proprietary fencing Q40/340 Steel vertical bar fencing Q40/40 Steel Q40/430 Proprietary fencing

Product range	Vertical Bar Railings LPS 1175 Certified Fencing

Posts	80 x 60 mm. Guidance for specification option: Rectangular hollow section (RHS) posts with anti-tamper fixings with internal connectors and no visible bolts.
Post foundations	Set in concrete. Guidance for specification option: Standard. Base-plated. Guidance for specification option: To bolt down onto concrete. Cranked.
Base boards	To bolt onto concrete.
Rails	60 x 40 mm. Guidance for specification option: Two rails.
Panels	1800 mm high: 25 x 25 mm pales with 124 mm pale centres. Guidance for specification option: Overall post length: 2500 mm; post centres: 3000 mm.
Fence topping	Manufacturer's standard.
Site applied finishes	Hot-dip-galvanized to BS EN 1461. Guidance for specification option: Standard. Galvanized and powder-coated, Black RAL 9005. Guidance for specification option: To BS EN 13438. Galvanized and powder-coated, Green RAL 6005. Guidance for specification option: To BS EN 13438. Galvanized and powder-coated, other. Guidance for specification option: Special order, insert requirements (BS or RAL). Marine coat. Guidance for specification option: For installations within 500 m of saltwater or an estuary.
System accessories	None. Finials. Guidance for specification option: Consult manufacturer for options and insert requirements. Matching gates. Guidance for specification option: To be specified separately.
