Canadian Western Red Cedar Timber Cladding

Name: Canadian Western Red Cedar Timber Cladding
Brand: Vincent Timber Ltd
SKU: 6kYXcQqKjsS53KskbeMj8g

Verified by manufacturer 6 days ago

VT1 Horizontal

Vincent Timber Ltd

Third party certifications:

Chain of Custody Certification
Certificate type

Softwood weatherboards for external timber cladding in a range of profiles and sizes. Suitable for private and commercial projects including housing, education, healthcare and offices.

Jump to:

+44 (0)121 772 5511 Website

Application

Imported Canadian Western Red Cedar softwood weatherboards for external timber cladding in a range of profiles and sizes, suitable for private, commercial and infrastructure projects, including:

Housing
Education
Healthcare
Offices
Retail

Other applications include external timber fins/ louvres on a range of structures:

Car park screening
Solar shading
Fencing

Description

Canadian Western Red Cedar is available in a wide range of profiles, widths and thicknesses offering flexibility in design.

A slow-grown, naturally durable species of timber with high resistance to decay.

A stable and lightweight timber, with a warmth complemented by a uniform fine grain which makes it easy to work with.
Left uncoated Canadian Western Red Cedar will naturally weather down to a silver/ grey colour.
The species is durable and does not need additional treatments or coatings applied.
Accepts stains and paints well if there is a desire to prolong a colour.
Can be fire treated to meet EuroClass B with pressure impregnation.
PEFC certified.

General information

Color	Brown
Finish	Smooth Textured Brushed Wood grain Woodgrain
Material	Timber
Shape	Rectangle Guidance for specification option: Profiled, Louvre, Fin.
Length	1830 mm 2130 mm 2440 mm 2740 mm 3050 mm 3350 mm 3660 mm 3960 mm 4270 mm 4570 mm 4880 mm 5180 mm 5490 mm 5790 mm 6100 mm Bespoke Show more
Width	44 mm 69 mm 92 mm 118 mm 142 mm Bespoke Show more

Uniclass	Pr_25_71_97_84 Softwood weatherboardsPrimary
CAWS	B91/460 Timber cladding H21/116 Horizontal timber weatherboarding H21/115 Vertical timber weatherboarding H21/111 Horizontal timber weatherboarding H21/110 Vertical timber weatherboarding H21/15 Horizontal timber weatherboarding H21/10 Vertical timber weatherboarding

Specification data - Softwood weatherboards

Standard	To BS EN 14915.
Third-party certification	PEFC certified.
Reaction to fire classification	To BS EN 13501-1, Class D-s2, d0. Guidance for specification option: In accordance with the SKBI (single burning item).
Thermal conductivity	0.13 W/m K.
Resistance to fixings	Guidance for specification option: Stainless steel fixings recommended.
Wood species	Canadian western red cedar.
Quality of timber (exposed surfaces)	To BS EN 14519, Grade A.
Profile	VT1.
Finished size	-
Face width	135 mm. Manufacturer guidance Other profiles are available in 44 mm and 69 mm face widths, consult manufacturer for details. Face cover excludes the recommended 2 mm expansion gap at installation.
Thickness	18 mm. Guidance for specification option: Standard cladding profiles.
Biological durability	-
Use class	To BS EN 335, Use Class 2.
Preservative treatment	Not required.
Flame-retardant treatment	Not required. Required (Euroclass B).

Surface texture	Smooth. Planed. Textured. Brushed.
Board length	1830 mm. 2130 mm. 2440 mm. 2740 mm 3050 mm. 3350 mm. 3660 mm. 3960 mm 4270 mm. 4570 mm. 4880 mm. 5180 mm 5490 mm. 5790 mm. 6100 mm. Show more
MoistureContent	12%. Guidance for specification option: Kiln dried product.
Density	350 kg/m3.
Accessories	Guidance for specification option: Consult manufacturer for details.
Applied finish	Not required. Paint coating. Guidance for specification option: Various colours available, consult manufacturer for details.

Sustainability data

Contains Red List materials	No
Country of material origin	Canada
Country of product manufacture	United Kingdom
Material	Timber
Recyclability	100% Recyclable
Recycled content As defined in clause 7.8 of BS EN ISO 14021	0 %

Third party certifications

Chain of Custody Certification

PEFC Certification - Vincent Timber

Literature

Canadian Western Red Cedar Timber Cladding Data Sheet

Case studies

Canadian Western Red Cedar Timber Cladding Private House Case Study

Manhattan Loft Gardens, London - Western Red Cedar Cladding
