Thermowood D Timber Cladding
Verified by manufacturer 6 days ago
VT2562 - Horizontal (secret fixed)
VT2562 - Horizontal (secret fixed)
Chain of Custody Certification
Certificate type
Softwood weatherboards for external timber cladding in a range of profiles and sizes. Suitable for private and commercial projects including housing, education, healthcare and offices.
Application
Thermowood D softwood weatherboards for external timber cladding in a range of profiles and sizes, suitable for private, commercial and infrastructure projects, including:
- Housing.
- Education.
- Healthcare.
- Offices.
- Retail.
Other applications include external timber fins/ louvres on a range of structures:
- Car park screening.
- Solar shading.
- Fencing.
Description
Thermowood comes in a range of sizes and is particularly suitable for use in exposed areas such as external cladding.
Thermowood is produced by treating softwood in special chamber kilns at high temperatures. The cellular structure changes during the heat treatment, and as a result, Thermowood is more stable than untreated wood in changeable climatic conditions.
Features and benefits:
- High resistance to moisture or decay-causing fungi.
- The production process uses heat, vapour and steam only and no chemicals that will have a detrimental effect on the environment.
- Accepts stains/ paints and FR treatments.
- Can also be left untreated to turn silver/ grey if a natural effect is required.
- PEFC certified.
General information
Color | Brown |
Finish | Smooth Textured Wood grain Woodgrain Sawn |
Material | Timber |
Shape | Rectangle Guidance for specification option: Profiled, Fin, Aerofoil. |
Length | 1800 mm 2100 mm 2400 mm 2700 mm 3000 mm |
Width | 44 mm 69 mm 98 mm 110 mm 122 mm |
Uniclass | |
CAWS | B91/460 Timber cladding H21/116 Horizontal timber weatherboarding H21/115 Vertical timber weatherboarding H21/111 Horizontal timber weatherboarding H21/110 Vertical timber weatherboarding H21/15 Horizontal timber weatherboarding H21/10 Vertical timber weatherboarding |
Specification data - Softwood weatherboards
Standard | To BS EN 14915. |
Third-party certification | PEFC certified. |
Reaction to fire classification | To BS EN 13501-1, Class D-s2, d0.Guidance for specification option: In accordance with the SKBI (single burning item). |
Thermal conductivity | 0.13 W/m K. |
Resistance to fixings | Guidance for specification option: Stainless steel fixings recommended. |
Wood species | European redwood. |
Quality of timber (exposed surfaces) | To BS EN 14519, Grade A/B. |
Profile | VT2562. |
Finished size | |
Face width | 122 mm.Guidance for specification option: Face cover excludes the recommended 2 mm expansion gap at installation. Manufacturer guidanceOther profiles are available in 44 mm and 69 mm face widths, consult manufacturer for details. |
Biological durability | |
Use class | To BS EN 335, Use Class 2. |
Flame-retardant treatment | Not required.Required (Euroclass B). |
Surface texture | Smooth. Planed. Textured. Brushed. |
Board length | 1800 mm. 2100 mm. 2400 mm. 2700 mm. 3000 mm. |
MoistureContent | 4–6%. |
Density | 350–480 kg/m3. |
Accessories | Guidance for specification option: Consult manufacturer for details. |
Applied finish | Not required. Paint coating. Guidance for specification option: Various colours available, consult manufacturer for details. |
Sustainability data
Contains Red List materials | No |
Country of material origin | Sweden Guidance for specification option: Sweden or Finland. |
Country of product manufacture | United Kingdom |
Material | Timber |
Recyclability | 100% Recyclable |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 0 % |
Third party certifications
Chain of Custody Certification
PEFC Certification - Vincent Timber
Literature
Thermowood D Timber Cladding Data Sheet
