Finger Safety Aluminium Hinge

Verified by manufacturer 1 month ago

Intastop Ltd

Specialist hinges to eliminate trapped fingers.

Jump to:
+44 (0) 1302 364 666 Website

Application

Eliminate the dangerous gap on the hinge side of the door preventing fingers being trapped.

Suitable for both new build and retrofit and designed to take impact.

Description

Finger Safety Hinges eliminate the dangerous gap on the hinge side of the door preventing fingers being trapped. They are ideal for use in nurseries, schools, nursing homes, healthcare establishments and wherever there is a risk of finger trapping. A fire rated, durable, long term solution lasting for the lifetime of the door.


Features:

  • Designed to leave enough space not to trap fingers.
  • Distributes loads stress uniformly along the full length of the door and frame.
  • Fire tested to BS 476-20 and -22 for 30 minutes.
  • Performance tested to 1.5 million cycles.


Benefits:

  • Ensures people safety in the event of a fire by maintaining fire integrity of the door allowing safe evacuation.
  • Prevent fingers being trapped in the back edge of the door.
  • Prevents door dropping and addresses door alignment issues to prevent damage to floor.
  • Reduces life cycle costs by prolonging the lifetime of a door.

General information

Finish

Satin

Material

Aluminium

Length

2100 mm

2400 mm

Uniclass

Pr_30_36_36_17 Cranked hingesPrimary

CAWS

L20/410 Wood doorsets

L20/420 Wood doorsets

L20/430 Wood doorsets

L20/480 Doorsets

L20/55 Doorsets

P21/320 Door hinges

P21/8 Door hinges

Product range

Hinges

Specification data - Cranked hinges

Form

Cranked.

Material and finish

Satin anodized aluminium (SAA).

Duty

Standard.

Guidance for specification option:

For doors up to 125 kg in weight.

Heavy.

Guidance for specification option:

For doors up to 245 kg in weight.

Length

2100 mm.

2400 mm.
