Technishield 50 rebated fire rated single glazed door 30/0 or 60/0

Name: Technishield 50 rebated fire rated single glazed door 30/0 or 60/0
Brand: Optima
SKU: mhSA9SwSrnyo4FS4RQ13uj

Verified by manufacturer 4 months ago

Third party certifications:

Fire-rated glass single door doorset. 30 or 60 minutes integrity.

Jump to:

Application

For use in conjunction with Technishield 50 partition system.

A framed, rebated, single-leaf, fire-rated glass doorset on hinges.

Features and benefits:

Color	White Silver Other
Finish	Powder-coated
Material	Glass Stainless steel Steel
Length	Bespoke
Width	Bespoke
Height	Bespoke
Warranty description	Three year Guidance for specification option: See Warranty Policy literature for more details.

Uniclass	Ss_25_30_20_25 Doorset systemsPrimary
CAWS	L20/480 Doorsets L20/55 Doorsets

Product range	Fire Range Doorsets

System performance	Fire performance.
Doorset	-
Type	Single leaf fire rated glass doorset.
Seals or inserts	-
Door	Manufacturer's standard. Guidance for specification option: Dropseal: Type RO drop seals. Door seals: Fire and smoke protection double seal.
Over panels	Not required. Over panel. Over panel and side panel. Guidance for specification option: Insert requirements
Side panels	Not required. Side panel both sides. Side panel left side. Side panel right side. Over panel and side panel. Guidance for specification option: Insert requirements
Hardware	Manufacturer's standard. Guidance for specification option: Hinges: Two face-fitted, weld-on hinges. Handles: Forster stainless steel lever handle set, fire-rated, cranked U-form steel cored with 9 mm spindle. Lock: Two-point fire-rated lever latch with Euro-cylinder operated deadlock. Euro cylinder: Cylinder and turn – 35 mm/ 35 mm. Door closer: TS-93 2-4. Other. Guidance for specification option: Insert requirements; contact manufacturer for information.
Samples required	Not required. Required.

FireRating	E30. Guidance for specification option: 30 minutes' integrity (30/0). E60. Guidance for specification option: 60 minutes' integrity (60/0).
Finish/ Colour	Powder-coated, RAL. Guidance for specification option: Insert requirement; contact manufacturer for more information. Powder-coated, RAL 9006 Silver. Guidance for specification option: 50 microns, 30% gloss (nominal). Powder-coated, RAL 9010 White. Guidance for specification option: 50 microns, 30% gloss (nominal).
Manifestation	Guidance for specification option: Insert requirements.
Size	Guidance for specification option: Door: With over-panel: Available 955–1230 x 2200–4000 mm (w x h); without over-panel: Available 955–1230 x 1800–3000 mm (w x h). All dimensions subject to specification and certification. Side panel: Available 300–1100 mm in width.
Configuration	As schedule. As drawing.

Country of material origin	United Kingdom
Embodied carbon A1-A3 (production stage) as defined in BS EN 15804	149 kg CO₂ eq/m² Self declared Guidance for specification option: See Environmental Product Declaration literature for LCA data.
