Technishield 65 rebated fire-rated double glazed door 30/30
Verified by manufacturer 4 months ago
BM Trada
Certificate type
30/30 fire-rated glass doorset, double door.
Application
For use in conjunction with Technishield 65 partition system.
Description
A framed, rebated, double-leaf, fire-rated glass doorset on hinges.
Features and benefits:
- Offering 30 minutes' integrity and insulation.
- Part M-compliant clear opening included.
General information
Color | Silver White Other |
Finish | Powder-coated |
Material | Glass |
Length | Bespoke |
Width | Bespoke |
Height | Bespoke |
Warranty description | Three year Guidance for specification option: See Warranty Policy literature for more details. |
Uniclass | |
CAWS | L20/480 Doorsets L20/55 Doorsets |
Product range |
Specification data - Doorset systems
System performance | Fire performance. |
Doorset | |
Type | Fire rated glass doorset. |
Seals or inserts | |
Door | Manufacturer's standard.Guidance for specification option: Dropseal: Type RO drop seals. Door seals: Fire protection double-seal. |
Over panels | Not required.Over panel.Over panel and side panel.Guidance for specification option: Insert requirements. |
Side panels | Not required.Side panel both sides.Side panel left side.Side panel right side.Over panel and side panel.Guidance for specification option: Insert requirements. |
Hardware | Manufacturer's standard.Guidance for specification option: Hinges: Two face-fitted, weld-on hinges per leaf. Handles: Forster stainless steel lever handle set, fire-rated, cranked U-form steel cored with 9 mm spindle. Lock: Two-point fire-rated lever latch with Euro-cylinder operated deadlock. Euro cylinder: Cylinder and turn – 35 mm/ 35 mm. Door closer: TS-93 2-4. Other.Guidance for specification option: Insert requirements; contact manufacturer for more information. |
Samples required | Not required.Required. |
Finish/ Colour | Powder-coated, RAL. Guidance for specification option: Insert requirement; contact manufacturer for more information. Powder-coated, RAL 9006 Silver. Guidance for specification option: 50 microns, 30% gloss (nominal). Powder-coated, RAL 9010 White. Guidance for specification option: 50 microns, 30% gloss (nominal). |
Manifestation | Guidance for specification option: Insert requirements. |
Fire rating | EI30 – 30 minutes' integrity and insulation (30/30). |
Size | Guidance for specification option:
|
Configuration | As schedule. As drawing. Guidance for specification option: Insert drawing reference number. |
Sustainability data
Country of product manufacture | United Kingdom |
Embodied carbonA1-A3 (production stage) as defined in BS EN 15804 | 159 kg CO₂ eq/m² Self declared Guidance for specification option: See Environmental Product Declaration literature for LCA data. |
BIM objects
| Platform | Compatible | Version |
|---|---|---|
 Revit | Revit 2017 | 2 |
Third party certifications
BM Trada
009109 (3) - ISO 14001 - Optima Products Limited
BM Trada
000016 (4) - ISO 9001 - Optima Products Limited
Literature
Optima Technishield Product Summary
000005 (3) - Warranty - Company Policy
Technishield 65 Fire Rated 30 Door EPD
