Ideal Standard Waverley Close Coupled WC

Verified by manufacturer 3 months ago

Ideal Standard (UK) Ltd Third party certifications:
  • EPD

    EPD

    Certificate type

Close coupled toilet bowl with horizontal outlet.

Jump to:
+44 (0)870 122 8822 Website

Application

Suitable for use as close coupled toilet bowl with horizontal outlet.

Description

The Waverley suite offers classic Edwardian styling with matching washbasin & toilet seat options.


Features and benefits:

  • Domestic and hotel use.
  • Classic Edwardian styling.
  • Traditional lever.
  • WC screwed to floor and cistern screwed to wall.
  • Seat available in 2 colour options

General information

Color

White

Finish

Polished

Material

Vitreous china

Length

675 mm

Width

360 mm

Height

440 mm

Warranty description

Lifetime

Uniclass

Pr_40_20_93_94 WC pansPrimary

CAWS

N13/10 WC pans and flushing arrangements

N13/300 WCs and cisterns

Specification data - WC pans

Standard

To BS EN 997.

Form

Back-to-wall, washdown.

Connecting dimensions

To BS EN 33.

Pan height

400 mm.

Materials

-

Body

Vitreous china.

Finish and colour

Polished.

Manufacturer guidance

White.

Water supply, outlet and seat holes

-

Water supply

Top inlet.

Outlet

Horizontal back outlet.

Seat holes

Standard pattern.

Dimensions

380 x 590 x 400 mm.

Guidance for specification option:

W x D x H.

Sustainability data

Contains Red List materials

No

Country of product manufacture

United Kingdom

Material

Vitreous china

Third party certifications

BIM objects

Platform Compatible Version
Revit
-

1

Third party certifications

EPD

EPD

EPD - Ceramic Vitreous China
