Magply A1 Non Combustible Drylining Board
Verified by manufacturer 24 hours ago
9 mm Thick
9 mm Thick
BS EN 13501-1
Certificate type
BBA Agrément Certificate
Certificate type
High strength, non-combustible drylining board.
Application
Suitable for various drylining and pattress board applications:
- Drylining
- Pattressing
- SFS infill
- Steel framing
- Timber frame
- Partition walls
- Boundary conditions
- Ceilings
- Suspended ceilings
Description
Euroclass A1 non-combustible drylining board.
Features and benefits:
- High strength, breathable board manufactured from magnesium sulphate (MOS) and reinforcement meshes which provide high dimensional stability
- Carries BBA Sheathing certification and has been tested to European Standards for fire integrity, insulation, racking strength, hygrothermal performance, acoustics, water absorption, impact and pull-out resistance.
- Available in a range of thicknesses.
- 9 mm Magply has been tested to provide a one-hour through wall solution.
- 12 mm-thick Magply has been tested to provide a two-hour through-wall solution in light gauge steel (LGS) frame.
- Odourless, non-combustible, insoluble in water, freeze/ thaw resistant, breathable and water-resistant, inert and has no nutritional value rendering it unattractive to insects and rodents.
- A1 non-combustible, racking strength, sound reduction.
- BBA Agrement Certificate.
- Tested at Lucideon, Exova and BUNCH.
General information
Color | White |
Finish | Smooth Textured |
Material | Mineral board |
Shape | Rectangle |
Length | 2400 mm |
Width | 1200 mm |
Height | 12 mm 18 mm 9 mm Manufacturer guidanceThickness. |
Uniclass | |
CAWS | K13/160 Proprietary K13/160 Proprietary K11/890 Board K11/795 Wall lining on metal framing K11/60 Board |
Specification data - Magnesium oxide boards
Classification data | |
Supplied by | Magply. |
Standard | Tested to BS EN 12467. |
Fire rating | To BS EN 476 (Parts 6 and 7), Class 0. To Euroclass EN 13501, A1 (Non-Combustible). |
Weather resistance | Freeze/ thaw resistant, breathable and water-resistant. |
Sheet size | |
Nominal thickness | 9 mm. |
Length | 2400 mm. |
Width | 1200 mm. |
Edges | Square. |
Finish as delivered | One smooth side and one textured side. Guidance for specification option: For Fire Resistant Applications use either Magply 4 Hour Intumescent Sealant or Magply A1 Filler Adhesive. |
Colour | Off white. |
Density | 1100 kg/m³. |
Thermal conductivity | 0.495 W/m·K. |
Moisture resistance | Class 1. |
Vapour resistance | To EN ISO 12572, 0.31 MNs/g. |
Odour | Odourless. |
Solubility in water | Insoluble. |
Release of dangerous substances | None. |
Freeze/ Thaw Resistance | To BS EN 12467, pass. |
Weight (per panel) | 28.5 kg. |
Technical characteristics, other | Heat rain performance to BS EN 12467, pass. Warm water performance to BS EN 12467, pass. Soak dry performance to BS EN 12467, pass. |
Sustainability data
Country of material origin | China |
Country of product manufacture | China |
Material | Mineral board |
Product certifications
BS EN 13501-1
Magply A1 Reaction to Fire
BBA Agrément Certificate
Magply Sheathing BBA Certificate
Literature
Literature type
Magply A1 Non Combustible Fire Protection Board - Datasheet
Magply A1 Brochure
