Magply A1 Non Combustible Roofing Board

Verified by manufacturer 6 days ago

6 mm Thick

Magply Variant:
Product certifications:
  • BS EN 13501-1

    BS EN 13501-1

    Certificate type

A1 Non Combustible, High strength roofing board.

Jump to:
01621 776252 Website

Application

Euroclass A1 non-combustible board, suitable for use in Roofing applications, particularly for waterproofing membranes, recovery boards, pitched roofing and overlay applications including;

  • Liquid waterproofing
  • Single ply membranes
  • Reinforced Bitumen Membranes
  • PMMA
  • Standing Seam systems
  • Pitched roofing
  • Solar PV
  • Sarking
  • Lead & hard metals
  • Soffits & fascia
  • Overlay applications

Description

Euroclass A1 non-combustible roofing board, available in a range of thicknesses for Roofing

Features and benefits:

  • High strength, breathable board manufactured from magnesium sulphate (MOS) and reinforcing mesh to provide high dimensional stability.
  • Has been tested to European Standards for fire integrity, insulation, racking strength, hygrothermal performance, acoustics, water absorption, impact and pull-out resistance.
  • Magply can be mechanically fixed or adhered as part of the roof system
  • 6mm Magply can be used to help achieve BroofT4 within roof system buildups
  • 12mm Magply can be used to overlay metal roof decks to provide a flat, non-combustible surface to lay the roofing system onto
  • Odourless, non-combustible, insoluble in water, freeze/ thaw resistant, breathable, water-resistant and mould resistant
  • A1 non-combustible board with Category 1 Racking strength and High screw pullout strength

General information

Color

White

Finish

Smooth

Textured

Material

Mineral board

Shape

Rectangle

Length

2400 mm

Width

1200 mm

Height

6 mm

9 mm

12 mm

18 mm

20 mm

Manufacturer guidance

Thickness.

Uniclass

Pr_25_71_52_50 Magnesium oxide boardsPrimary

CAWS

K11/890 Board

G20/99 Fascias/ barges/ soffits

G20/950 Fascias/ barges/ soffits

Specification data - Magnesium oxide boards

Supplied by

Magply.

Standard

Tested to BS EN 12467.

Fire rating

To BS EN 476 (Parts 6 and 7), Class 0.
To Euroclass EN 13501, A1 (Non-Combustible).

Weather resistance

Freeze/ thaw resistant, breathable and water-resistant.

Sheet size

-

Nominal thickness

6 mm.

Manufacturer guidance

Thickness variants depend on roofing applications; consult manufacturer for more details.

Length

2400 mm.

Width

1200 mm.

Edges

Square.

Finish as delivered

One smooth side and one textured side.

Guidance for specification option:

For Fire Resistant Applications use either Magply 4 Hour Intumescent Sealant or Magply A1 Filler Adhesive.

Colour

Off white.

Density

1100 kg/m³.

Thermal conductivity

0.495 W/m·K.

Moisture resistance

Class 1.

Vapour resistance

To EN ISO 12572, 0.31 MNs/g.

Odour

Odourless.

Solubility in water

Insoluble.

Release of dangerous substances

None.

Freeze/ Thaw Resistance

To BS EN 12467, pass.

Weight (per panel)

19.0 kg.

Technical characteristics, other

Heat rain performance to BS EN 12467, pass.
Warm water performance to BS EN 12467, pass.
Soak dry performance to BS EN 12467, pass.

Sustainability data

Contains Red List materials

No

Country of material origin

China

Country of product manufacture

China

Material

Mineral board

Product certifications

BS EN 13501-1

BS EN 13501-1

Magply A1 Reaction to Fire
