Rapidor Impact – Self-repairing High Speed Door

Name: Rapidor Impact – Self-repairing High Speed Door
Brand: Tekta UK
SKU: 5MYpEb1wzBnARUtaAK8svz

Verified by manufacturer 6 months ago

Rapidor Impact

Tekta UK

Third party certifications:

Alcumus SafeContractor
Certificate type
ISO 9001 Quality Management
Certificate type
Constructionline Gold
Certificate type
CHAS
Certificate type

The Rapidor Impact is a high speed, self-repairing door range, specifically designed for high use doorways where a barrier is needed without inhibiting operational effectiveness.

Jump to:

+ (44) 0330 7000 333 Website

Application

Food production facilities.
Distribution.
Warehouse.
Internal and external openings.

Description

This door offers a quiet and reliable operation and is available with opening speeds up to 2.5 m/s, maximizing efficiency. With its zipper edge curtain, the door gives an excellent seal. This feature, combined with the door’s soft bottom edge enables the curtain to self-repair in the event of an impact, reducing maintenance and repair costs.

The curtains are constructed from a tough PVC-coated fabric, available in various colours and with transparent vision panels. Bespoke door constructions can be supplied to suit specialist areas such as; freezer rooms, ATEX areas or air-tight clean rooms.

Available with a variety of safety features, such as; light curtains, traffic lights and audio warnings, this range is tested to fully comply with the relevant European safety standards. The doors can be operated by; radar sensor, induction loop, remote control or pushbutton and can be interlocked to suit specific requirements.

Features and benefits:

Quiet and reliable operation.
Opening speeds of up to 2.5 m/s.
Impact-resistant and self-repairing.
Hygienic seal.

General information

Color	Black Blue Brown Grey Green Ivory Orange Red Yellow White Show more Manufacturer guidance Curtain colour.
Finish	Galvanized Stainless steel Powder-coated
Material	Steel Stainless steel Fabric Polyvinyl chloride (PVC)
Shape	Square Rectangle
Width	Bespoke
Height	Bespoke
Warranty description	One year Guidance for specification option: One year parts and labour warranty as standard. Consult manufacturer for extended warranty and lifelong service options.

Uniclass	Pr_30_59_24_38 High-speed doorsetsPrimary
CAWS	L20/570 High-speed doors

Product range	Rapidor Speed Doors

Specification data - High-speed doorsets

Speed (minimum)	-
Opening	2.5 m/s (maximum).
Closing	0.8 m/s.
Format	Rolling rapid rise door.
Arrangement	Vertically operating high speed roller door for face fixing.
Curtain material	PVC.
Frame and guides	-
Material	Galvanized Steel. Stainless steel. Manufacturer guidance Two-part steel guide with a self-lubricating polyethylene runner.
Finish and colour	Powder-coated. Stainless steel. Galvnized.
Operation	Push button. Guidance for specification option: Standard. Remote control. Guidance for specification option: Optional. Poximity sensors. Guidance for specification option: Optional. Pull cord. Guidance for specification option: Optional. Induction loop Guidance for specification option: Optional. Radar sensor. Guidance for specification option: Optional. Manufacturer guidance Electric operation via direct drive three-phase 415 V motor complete with emergency brake release at low level; safety light curtain for obstacle detection up to 2500 mm above floor level; three button push to run control panel; Radar motion sensors.

Standards	To EN 13241, EN 12604, EN 12426 Class 3, EN 12425 Class 1, EN 12424.
Power supply	Single phase, 240 V. Guidance for specification option: Single phase available for doors up to 3000 x 3000 mm. Three phase, 415 V. Guidance for specification option: Standard.
Safety	Light curtain safety sensor and flashing warning beacon Guidance for specification option: Optional. Audio warning siren. Red/Green traffic lights. Count-down traffic lights.
Vision panels	Not required. 300 mm high rectangular-rounded. Guidance for specification option: Standard. 500 mm high rectangular vision window. Guidance for specification option: Optional.
Air permeability	Class 1.
Resistance to water penetration	Class 3.
Dimensions	- Manufacturer guidance Size (w x h): 4500 x 4500 mm (maximum). Insert requirements.
Curtain colour	RAL 9010. RAL 1015. RAL 2004. RAL 3002. RAL 1003. RAL 6018. RAL 6026. RAL 5012. RAL 5002. RAL 5010. RAL 7037. RAL 7042. RAL 7035. RAL 9006. RAL 8017. RAL 7016. RAL 9005. Show more
Type:	The Rapidor Impact high speed doors minimizes energy loss through frequently used openings.
