Application

Suitable for public changing areas.

Description

Features and benefits:

  • Integrated bench seating.
  • Manufactured from 12/ 13 mm solid grade laminate.
  • Wear and water resistant solution in a wide range of colours.
  • D-shaped satin anodized aluminium headrail with aerofoil profile.

General information

Color

-

Manufacturer guidance

To be confirmed from WW standard SGL range, subject to depth of partition.

Material

Solid grade laminate (SGL)

Size

-

Manufacturer guidance

1950 mm overall height including 150 mm floor clearance.

Width

-

Manufacturer guidance

1500–1800 mm.

Height

1950 mm

Warranty description

One year

Guidance for specification option:

From practical completion.

Uniclass

Ss_25_12_60_60 Panel cubicle systemsPrimary

CAWS

K32/10 Panel cubicles

K32/120 Panel cubicles

Product range

Forté

Specification data - Panel cubicle systems

Panels

12/ 13 mm solid grade laminate (SGL).

Manufacturer guidance

A wide range of laminates available, please contact manufacturer for details.

Panel supports

Satin anodized aluminium pedestal legs.

Pilasters

12/ 13 mm solid grade laminate (SGL).

Manufacturer guidance

A wide range of laminates available, please contact manufacturer for details.

Doors

12/ 13 mm solid grade laminate (SGL).

Manufacturer guidance

A wide range of laminates available, please contact manufacturer for details.

Lippings

Exposed edges machined to a smooth finish with radiused safety corner details to doors and pilasters.

Hardware

Stainless steel 4 inch butt hinges.

Full length SAA channel cleats.

Coat hook.

Easily operable indicator bolt.

Legs

Tubular and rounded off design manufactured from satin anodized aluminium, fixed to partition panel. Adjustable to suit uneven floor levels.

Seating

Complete with integral legato model 1 bench seat, 300 mm deep in solid grade laminate.

Other requirements

Where indicated on drawings supplied, outward opening doors have been allowed complete with satin polished stainless steel pull handles to the outside face of the doors.

Colour

-

Manufacturer guidance

To be confirmed from WW standard SGL range, subject to depth of partition.

Sustainability data

Country of product manufacture

United Kingdom
