Resin Flooring System FasTop® SL ESD

Name: Resin Flooring System FasTop® SL ESD
Brand: Sherwin-Williams
SKU: wo9XZEdt1kSH4k8qqqEe3i

Verified by manufacturer 5 months ago

Sherwin-Williams

Static-dissipative polyurethane cement self-smoothing floor system.

Jump to:

+44 (0)1204 521771 Website

Application

For use in:

EV battery plants.
Laboratories.
Electronic production areas.
Workshops.
Printing and packaging areas.
Food manufacture and processing.
Power station areas.
Film and TV studios.
Automotive production.
Pharmaceutical and chemical plant processing.

Description

FasTop SL ESD is a static-dissipative resin based flooring system which is installed at 3 mm nominal thickness providing an electrical conductivity leakage resistance of <10^6 ohms when tested to BS EN 61340-4- 1:2004+A1:2015.

The system comprises conductive fillers with selected polyurethane cement resin components and pigments to provide a finish that is resistance against chemical attack and abrasion. It is particularly suited for production areas and clean room type situations where a matt static-dissipative smooth tough and hygienic floor is required.

Features and benefits:

Seamless.
Static dissipative.
Silica free.
Hard-wearing.
Hygienic.
Excellent chemical resistance.
Smooth finish for precise operating equipment.
FerFa class: 5.
Full curing time of eight days (at 10°C); five days (at 30°C).
Protects sensitive electronics from static charge
Protects people from static charge

General information

Color	Grey Beige Blue Cream Yellow Orange Green Red Show more
Finish	Matt Smooth
Material	Polyurethane Resin
Shape	Formless
Length	Bespoke
Width	Bespoke
Height	3 mm
Warranty description	Other

Uniclass	Ss_30_42_54_75 Resin flooring systemsPrimary
CAWS	M12/110 Resin flooring M12/10 Resin flooring

Specification data - Resin flooring systems

Substrate	-
Testing	Moisture content to BS 8204.
Preparation	Preparation of existing substrates. Guidance for specification option: Substrates must be clean, sound, dry and free of surface laitance with a minimum strength of 25 N/mm². Mechanically prepare substrate to provide a surface texture that will function as a key for the resin. Remove all dust and debris. Repair significant mechanical damage, pitting and cracks.
Levelling screed	FasTop Multi SL ESD.
Primer	Not required. Resuseal clear. Guidance for specification option: Optional. Resuprime ESD. Guidance for specification option: ESD primer.
Movement joints	-
Type	Not required. Epo-Flex™ VJ. Guidance for specification option: The spacing and type of joints should be determined prior to the resin floor system being installed. Mix Epo-Flex VJ Part A (base) with Epo-Flex VJ Part B (hardener). These units are in pre-weighed containers. Mix using a low speed mixer and paddle (300–400 rpm) for 2–3 minutes, until a uniform mixed product is obtained. Apply the Epo-Flex VJ immediately to the prepared and cut joints with a knife to a consistent smooth finish.

Abrasion resistance	To BS EN 13892-4:2002, AR 0.5.
CompressiveStrength	To BS EN ISO 604:2003, 43 MPa.
TensileStrength	To BS EN ISO 527-2:2012, 7 N/mm².
Flexural strength	BS EN ISO 178:2010+A1:2013, 26 N/mm².
Bond strength	To BS EN 13892-8:2002, >3 N/mm².
Impact resistance	To BS EN 6272-1:2011, >4.
Temperature resistance	Up to 80°C (at 3 mm).
Application temperature	10–25ºC.
Reaction to fire	To BS EN 13501-1:2018, Bfl–s1.
System thickness	3 mm.
Tape	Copper tape. Manufacturer guidance earthing tape.
