Polyurethane cement self-levelling floor screed system.
Suitable for use in:
A 4–5 mm thick polyurethane cement, UV stable self-levelling resin floor system which provides a heavy-duty finish with resistance against chemical attack and hot water. It is a food grade, non-taint odourless product available with a satin or matt finish, providing maximum hygienic standards ideal for industrial and production areas.
Features and benefits:
Color | Black Blue Green Grey Orange |
Finish | Matt Satin |
Material | Polyurethane Resin |
Length | Bespoke |
Width | Bespoke |
Height | Bespoke |
Warranty description | Five year |
Uniclass | |
CAWS | M12/10 Resin flooring M12/110 Resin flooring |
Substrate | |
Preparation | Preparation of existing substrates.Preparation of new substrates. |
Levelling screed | Guidance for specification option: Insert requirement, consult manufacturer for information. |
Primer | One coat Resuprime MVT.Guidance for specification option: Standard, for use if the concrete substrate moisture levels are above 75% equilibrium relative humidty (ERH) or no damp proof membrane is present. Two coats Resuprime MVT.Guidance for specification option: For use if the concrete substrate moisture levels are particularly high. Resin coating primers. |
Resin flooring | Resupen WB Colour.Guidance for specification option: Consult manufacturer for information. Resin floor coatings.Flow applied flooring.Heavy-duty flow-applied flooring.Multilayer flooring. |
Movement joints | |
Type | Resin flooring strip movement joints. |
Resin skirtings and upstands | FasTop Multi WR.Render-grade resins. |
Execution | Workmanship.Application of primers.Surface abrading and polishing.Applying surface sealers.Applying surface finishes.Retention of resin edges.Installing strip movement joints. |
System thickness | Manufacturer guidance4—5 mm. |
Reaction to fire (to EN 13501-1) | Bfl-s1. |
Curing time | 12—16 hours. Guidance for specification option: (at 20ºC) Light traffic. 48—72 hours. Guidance for specification option: (at 20ºC) Designed traffic. 5—7 days. Guidance for specification option: (at 20ºC) Full cure traffic. |
Hardness | 80. Guidance for specification option: After 24 hours. Manufacturer guidanceShore D. |
Abrasion resistance | To BS EN 13892-5 and BS ISO 7619-1, AR 0.5 |
CompressiveStrength | To BS EN ISO 604, 54 MPa. |
Flexural strength | To BS EN ISO 178+A1, 14 N/mm². |
Bond strength | To BS EN 13892-8, >3 N/mm². Guidance for specification option: Substrate failure. |
Impact resistance | To BS EN 6272, >4. |
Temperature resistance | 90°C. Guidance for specification option: At 3 mm. Manufacturer guidanceTolerant of temperatures up to: |
Chemical resistance | Excellent. |
UV stabilization | Yes. |
Performance | Manufacturer guidance
|
Testing | Manufacturer guidance
|
Contains Red List materials | No |
Country of material origin | United Kingdom |
Country of product manufacture | United Kingdom |
