Resin flooring system FasTop™ TG69 - Resin floor screed

Verified by manufacturer 5 months ago

Sherwin-Williams Third party certifications:
  • European Technical Approvals

    European Technical Approvals

    Certificate type

  • ISO 14001 Environmental Management Systems

    Certificate type

  • ISO 9001 Quality Management

    Certificate type

FasTop TG69 is a very heavy duty antimicrobial polyurethane cement floor screed system, providing superb resistance against chemical attack, thermal shock.

Jump to:
+44 (0)1204 521771 Website

Application

Heavy-duty polyurethane cement floor screed system suitable for use in:

  • Food manufacture and processing.
  • Brewing and beverage.
  • Dairies.
  • Commercial kitchens.
  • Pharmaceutical manufacturing.
  • Chemical plants.
  • Abattoirs and meat processing facilities.
  • Heavy-duty plant and traffic areas.
  • Workshops.

Description

A very heavy-duty polyurethane cement floor screed system providing excellent resistance against chemical attack, thermal shock and abrasion which is HACCP International certified. It is a food grade non-taint and odourless product which can incorporate an antimicrobial additive and provide slip resistance in wet and dry conditions.


When installed at 9 mm thickness, the system is resistant to steam cleaning, boiling water and process liquids up to 120ºC and is also suitable for freezer temperatures down to -40ºC.


Features and benefits:

  • High chemical resistance.
  • Food safe and non-taint (Campden BRI approved).
  • HACCP certified
  • Resistance to hot water and steam.
  • Self-sealing- No topcoat required
  • Excellent slip-resistant finish.
  • Matt finish system.
  • Extremely hard wearing.
  • Non dusting.
  • CE Marked to BS EN 13813.

General information

Color

Finish

Matt

Anti-microbial

Anti-slip

Anti-skid

Material

Polyurethane

Resin

Cement

Water-borne

Length

Bespoke

Width

Bespoke

Height

Bespoke

Warranty description

Ten year

Uniclass

Ss_30_42_54_75 Resin flooring systemsPrimary

CAWS

M12/10 Resin flooring

M12/110 Resin flooring

Specification data - Resin flooring systems

System performance

Slip resistance

Durability

Water and vapour resistance

Environmental conditions in service

Compliance with performance requirements

Flatness and surface regularity

Substrate

-

Testing

Moisture content to BS 8204.

Preparation

Preparation of existing substrates.

Guidance for specification option:

Substrates must be clean, sound, dry and free of surface laitance with a minimum strength of 25 N/mm². Mechanically prepare substrate to provide a surface texture that will function as a key for the resin. Remove all dust and debris. Repair significant mechanical damage, pitting and cracks.

Primer

Not required.

FasTop Multi Primer.

Guidance for specification option:

Optional.

Resin coating primers

Resin flooring

FasTop Multi TG69.

Guidance for specification option:

Screed.

Heavy-duty screed flooring

Screed flooring

Movement joints

-

Type

Continue functioning subfloor joints.

Guidance for specification option:

 Through the resin flooring system and fill with Epo-Flex VJ.

Resin skirtings and upstands

FasTop Multi WR.

Guidance for specification option:

Coved skirtings.

Execution

Workmanship

Application of primers

Applying surface finishes

Forming upstands

Retention of resin edges

System completion

Testing slip resistance

Testing bond strength

Verification of performance

System thickness

6–9 mm

Reaction to fire (to EN 13501-1)

Bfl - s1.

Curing time

12—16 hours.

Guidance for specification option:

(at 20ºC) Light traffic.

36—48 hours.

Guidance for specification option:

(at 20ºC) Designed traffic.

5—7 days.

Guidance for specification option:

(at 20ºC) Full cure traffic.

Hardness

To BS ISO 7619-1, 72.

Guidance for specification option:

After 24 hours.

Manufacturer guidance

Shore D.

Abrasion resistance

To BS EN 13892-5, AR 2.

CompressiveStrength

To BS EN 13892-2, 52.9 N/mm².

TensileStrength

To BS 6319-7, 1.9 N/mm².

Flexural strength

To BS EN 13892-2, 5.6 N/mm².

Bond strength

To BS EN 13813, >3 N/mm².

Guidance for specification option:

Substrate failure.

Impact resistance

To BS EN ISO 6272, >4.

Temperature resistance

120°C.

Guidance for specification option:

At 9 mm.

Manufacturer guidance

Tolerant of temperatures up to :

Chemical resistance

Excellent.

UV stabilization

No.

Colour

Black.

Blue.

Buff.

Green.

Salsa.

Show more

Sustainability data

Contains Red List materials

No

Country of material origin

United Kingdom

Country of product manufacture

United Kingdom

Embodied carbon

A1-A3 (production stage) as defined in BS EN 15804

1.19 kg CO₂ eq/kg

Self declared

Recycled content

As defined in clause 7.8 of BS EN ISO 14021

15 %
