Resin Flooring System Resuflor Topfloor X

Verified by manufacturer 3 months ago

Sherwin-Williams Third party certifications:
  • ISO 9001 Quality Management

    Certificate type

A self-levelling epoxy resin floor system which provides a flat hard-wearing gloss finish at 3 mm thickness following the profile of the existing floor.

Jump to:
+44 (0)1204 521771 Website

Application

Epoxy resin self-smoothing floor system suitable for use in:

  • Laboratories.
  • Studios.
  • Workshops.
  • Printing and packaging areas.
  • Food manufacture and processing.
  • Brewing and beverage.
  • Cultivation facilities.
  • Automotive production.
  • Pharmaceutical and chemical plant processing.

Description

A self-levelling epoxy resin floor system which provides a flat hard-wearing gloss finish at 3 mm thickness following the profile of the existing floor. The system provides aesthetically pleasing results with resistance against chemical attack and abrasion. It is ideal for production areas and clean room type situations where a smooth and tough hygienic floor is required and also for studios and workshops where a modern functional finish is essential.


System includes:

  • Substrate.
  • Primer: Resuprime ST (second coat optional).
  • Screed: Resuflor SL X.


Features and benefits:

  • Seamless.
  • Gloss finish.
  • Silica free.
  • Extremely hard wearing.
  • Hygienic.
  • Good chemical resistance.
  • Smooth finish for precise operation equipment.

General information

Color

Finish

Gloss

Smooth

Anti-slip

Material

Epoxy resin

Warranty description

Five year

Uniclass

Ss_30_42_54_75 Resin flooring systemsPrimary

CAWS

M12/10 Resin flooring

M12/110 Resin flooring

Specification data - Resin flooring systems

Substrate

-

Testing

Moisture content to BS 8204.

Preparation

Preparation of existing substrates.

Guidance for specification option:

Substrates must be clean, sound, dry and free of surface laitance with a minimum strength of 25 N/mm². Mechanically prepare substrate to provide a surface texture that will function as a key for the resin. Remove all dust and debris. Repair significant mechancial damage, pitting and cracks.

Preparation of new substrates.

Primer

Resuprime ST .

Guidance for specification option:

Second coat optional.

Resin coating primers.

Resin flooring

Resuflor VF.

Guidance for specification option:

Screed.

Flow applied flooring.

Heavy-duty flow-applied flooring.

Movement joints

-

Type

Continue functioning joints.

Guidance for specification option:

In the subfloor through the resin flooring system and fill with Epo-Flex VJ.

Resin skirtings and upstands

Resuscreed 45.

Guidance for specification option:

Coved skirtings.

Render-grade resins.

Execution

Workmanship.

Application of primers.

Surface abrading and polishing.

Applying surface finishes.

Retention of resin edges.

Installing strip movement joints.

System thickness

3 mm.

Hardness

To BS ISO 7619-1, 83.

Guidance for specification option:

After 24 hours.

Manufacturer guidance

Shore D.

Abrasion resistance

To BS EN 13892-4, AR 0.5.

CompressiveStrength

To BS EN ISO 604, 42.6 MPa.

TensileStrength

To BS EN ISO 527-2, 15 MPa.

Flexural strength

To BS EN ISO 178, 45 N/mm².

Guidance for specification option:

2010+A1.

Bond strength

3 N/mm².

Impact resistance

To BS EN ISO 6272-1, >4.

Temperature resistance

60°C.

Manufacturer guidance

Tolerant of temperatures up to:

Reaction to fire (EN 13501-1)

Bfl–s1.

Chemical resistance

Good.

UV stabilization

No.

VOC content

Guidance for specification option:

81—85 g/L. Varies depending on product.

Coverage

Up to 15 m².

Guidance for specification option:

Varies depending on the product.

Cure time

8 hours to 8 days.

Guidance for specification option:

Depends on traffic conditions and temperature

Application temperature

Guidance for specification option:

10—25°C. An equilibrium relative humidity (ERH) <90%.

Performance

-

Manufacturer guidance

  • Slip resistance.
  • Durability.
  • Water and vapour resistance.
  • Flatness and surface regularity.

Testing

-

Manufacturer guidance

  • Testing slip resistance.
  • Testing bond strength.
  • Verification of performance.

Sustainability data

Country of product manufacture

United Kingdom

Third party certifications

ISO 9001 Quality Management

ISO 9001 Quality Management

ISO 9001

Literature

Resin flooring Resuflor Topfloor X system

Resin flooring Resuflor Topfloor X system

A guide to Sherwin-Williams Industrial Resin Flooring

A guide to Sherwin-Williams Industrial Resin Flooring

RAL Colour Card - Resuflor™, Resupen, Resutile™

RAL Colour Card - Resuflor™, Resupen, Resutile™
